1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
We recommend:
Read through the complete text in the operating instruc-
tions before installing and commissioning the device.
The operating instructions are intended to help the user
to become familiar with the machine and take advan-
tage of its application possibilities in accordance with
the recommendations.
The operating instructions contain important infor-
mation on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, costly
repairs, reduce downtimes and how to increase reliabil-
ity and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula-
tions that apply for the operation of the machine in your
country.
Keep the operating instructions package with the ma-
chine at all times and store it in a plastic cover to protect
it from dirt and moisture.
Read the instruction manual each time before operat-
ing the machine and carefully follow its information. The
machine can only be operated by persons who were
instructed concerning the operation of the machine and
who are informed about the associated dangers. The
minimum age requirement must be complied with.
In addition to the safety notices contained in this op-
erating manual and the particular instructions for your
country, the generally recognised technical regulations
for the operation of identical devices must be complied
with.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions and
the safety information.
22 | GB

2. Device description (Fig. 1)

1. Cutting device
2. Hand guard
3. Front handhold
4. Choke
5. Cranking rope with handle
6. ON / OFF-switch
7. Throttle lock-out switch
8. Air filter cover
9. Wing screw
10. Zerk fitting (grease fitting)
11. Fuel pump
12. Fuel tank cap
13. Slider
14. Throttle trigger
15. Rear handle
16. Spark plug connector
17. Knives protection
18. Allen key (size 5)
19. Allen key (size 4)
20. Open-ended spanner (8 mm / 10 mm)
21. Spark plug socket spanner
22. Mixing bottle
23. Safety googles
24. Gloves

3. Scope of delivery

Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available). Check that
the delivery is complete. Check the device and ac-
cessory parts for transport damage. If possible, store
the packaging until the warranty period has expired.
• Read the operating instructions to make yourself
familiar with the device prior to using it.
• Only use original parts for accessories as well as
for wearing and spare parts. Spare parts are avail-
able from your specialized dealer.
• Specify our part numbers as well as the type and
year of construction of the device in your orders.
m Attention
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, film and small parts! There is a risk of swallow-
ing and suffocation!
Petrol Hedge trimmer
Knives protection (17)
Spark plug socket spanner (21)
Mixing bottle
Allen key size 5 (18)
Allen key size 4 (19)
Open-ended spanner 8 + 10 (20)
Manual
