Consult an electrician!
*Specialist knowledge required for installation:
The following specialist knowledge is particularly important during ins-
tallation:
• The "5 safety rules" to be used:disconnect from mains; safegu-
ard from switching on again; check that no voltage is present in
system; earth and short circuit; cover or cordon off neighbouring
live parts;
• Select suitable tool, measuring equipment and, if necessary, per-
sonal safety equipment;
• Evaluation of measuring results;
• Selection of electrical installation material for safeguarding shut-
off conditions;
• IP protection types;
• Installation of electrical installation material;
• Type of supply network (TN system, IT system, TT system) and
the resulting connecting conditions (classical zero balancing,
protective earthing, required additional measures etc.).
5.2.4

Installation in multiple combinations

You can mount the wall thermostat with the attachment frame (A) provi-
ded or use it with frames of other manufacturers as well as integrate the
electronic unit (B) into a multi-gang frame. You can flexibly fix the moun-
ting plate (F) to the wall using adhesive strips or screws. For mounting
with multiple combinations, make sure that the mounting plate of the
wall thermostat is seamlessly aligned to the already fixed mounting plate/
retaining ring.
The wall thermostat is designed to fit into frames supplied by the follow-
ing manufacturers:
Manufacturer
Berker
ELSO
Frame
S.1, B.1, B.3, B.7 glass
Joy
Start-up
37
