Function and device overview
and removed very easily with the supplied clip-on frame using screws
or adhesive strips. It is compatible with a number of different surfaces
including furniture, brick walls, tiles or glass. It is also possible to integrate
the wall thermostat into existing switches.
Device overview (see figure 1):
(A) Clip-on frame
(B) Electronic unit (thermostat)
(C) Display
(D) System button (pairing button and LED)
(E) Control wheel
(F) Mounting plate
Display overview (see figure 2):
Set/actual temperature
Humidity
Warning about condensation
Open window symbol
Battery symbol
Radio transmission
Boost function
Manual operation
Automatic mode
Holiday mode
Heat
Cool
Operating lock
Setpoint temperature
