Exsys EX-43073 Bedienungsanleitung

EX- EX EX - - 43073 43073 43073
JUMPER SETTING & CONNECTORS:
JP4:
JP4 to DIS = Parallel Port disable (Factory setting)
DIS/ENA
JP4 to ENA = Parallel Port enable (no function)
Attention! This jumper has no function for the EX-43372.
DB9M:
Serial 9 Pin D-SUB male connector (S1 and S2):
Pin Signal Pin
1 CDC 4
2 RXD 5 GROUND
3 TXD 6
HARDWARE INSTALLATION :
If you are ready with the jumper settings, please proceed with the following installation
instructions. Because the designs of computers are different, only general installation
instructions are given. Please refer your computer's reference manual whenever in doubt.
1. Turn off the power to your computer and any other connected peripherals.
2. Remove the mounting screws located at the rear and/or sides panels of your Com-
puter and gently slide the cover off.
3. Locate an available expansion slot and remove its covers from the rear panel of your
computer. Make sure it is the right expansion slot for the card (see card description)
4. Align the card with the expansion slot, and then gently but firmly, insert the card.
Make sure the card is seated and oriented correctly. Never insert the card by force!
5. Then connect the card with a screw to the rear panel of the computer case.
6. Gently replace your computer's cover and the mounting screws.
DRIVER INSTALLATION :
Windows 9x/2000/XP/Vista & 7:
After starting Windows it recognizes a new "PCI Controller" and open the hardware
assistant. Please choose manual installation and put the driver CD into your CD-Rom
drive. Now enter the Path "D:\IO\OXFORD\" and then the directory of your operating
system "95_98_ME" "2000" "XP32" "XP64" "Vista32" "Vista64" "Win7_32bit" or
"Win7_64bit" into the box for the Path/Source and click at >next/continue<. Now
Windows search for the drivers in the specified directory. Follow the hardware assistant
and finish the installation. If Windows recognizes other new devices repeat the above
described steps. Attention! Restart Windows in any case after installing the drivers.
CHECK THE INSTALLED DRIVER:
Click at Start<>Run< then enter "compmgmt.msc" and click at >OK<. In the windows
that open select >Device Manager<. Under "Ports (COM and LPT)" you should find
one or more new "PCI Ports" as sample (COM3). If you see this or similar entries the
card is installed correctly.
CHANGE PORT NUMBER:
If you like to change the port number for example COM 3 to COM5, open the >Device
Manager< click at >COM3<, >Settings< and then >Advance<. There you can change
between COM 3 to 256.
5
English English English EX EX- EX - - 43073 43073 43073
DRIVER INSTALLATION :
Windows Server 200x:
After starting Windows it recognizes a new "PCI Controller" and open the hardware
assistant. Please choose manual installation and put the driver CD into your CD-Rom
drive. Now enter the Path "D:\IO\OXFORD\" and then the directory of your operating
system for Server 2000: "2000" for Server 2003: "XP32" or "XP64" and for Server
2008: "Vista32" or "Vista64" into the box for the Path/Source and click at >next/
continue<. Now Windows search for the drivers in the specified directory. Follow the
hardware assistant and finish the installation. If Windows recognizes other new devices
repeat the above described steps. Attention! Restart Windows in any case after install-
ing the drivers.
Signal Pin Signal
CHECK THE INSTALLED DRIVER:
DTR 7 RTS
Click at Start<>Run< then enter "compmgmt.msc" and click at >OK<. In the windows
that open select >Device Manager<. Under „Ports (COM and LPT)" you should find
8 CTS
one or more new "PCI Ports" as sample (COM3). If you see this or similar entries the
DSR 9 RI
card is installed correctly.
CHANGE PORT NUMBER:
If you like to change the port number for example COM 3 to COM5, open the >Device
Manager< click at >COM3<, >Settings< and then >Advance<. There you can change
between COM 3 to 256.
LINUX:
There are no drivers available for Linux, but the card is supported by the most versions
of Linux. Because each individual distribution and kernel version of Linux is different,
sadly we cant provide a installation instruction. Please refer to the installation manual
for standard IO ports from your Linux version! In some newer versions the card will
even be installed automatically after starting Linux.
English English English
JP2: +5V oder +12V
S2:
S1:
Die EX-43073 ist eine PCI serielle RS-232 Karte mit zwei seriellen FIFO 16C95x Ports,
für den Anschluss von High-Speed seriellen RS-232 Peripherie Geräten (z.B. Terminal,
Modem, Plotter usw.). Sie unterstützt den 32 und 64-Bit PCI bzw. PCI-X Bus mit 5 Volt
und 3,3 Volt. Es ist nicht möglich die I/O Adressen und Interrupts manuell einzustellen,
da die Einstellungen der Karte vom System (BIOS) und beim Installieren des Betriebs-
systems automatisch vorgenommen werden. Es besteht bei Bedarf die Möglichkeit, +5V
- oder +12V auf einen von vier Pins der Stecker zu legen (POS System).
Kompatibilität:
Betriebssysteme:
Anschlüsse:
Lieferumfang:
Zertifikate:
Mit der EX-43073 haben Sie die Möglichkeit +5V- oder +12V auf einen der folgenden
vier Pins, des 9 Pin Steckers S1 und S2 zu konfigurieren :
Achtung !! Nur konfigurieren wenn für das Peripheriegerät auch +5Volt oder +12Volt
gebraucht wird. Für normale Anwendungen, Jumper nicht verändern.
JP1 & JP2:
(S1 + S2)
J4:
6
Bedienungsanleitung Bedienungsanleitung
Vers. 1.0 / 05.08.10
AUFBAU :
einstellbar auf
den 9 Pin von S2
9 Pin Stecker
Seriell Anschluss
9 Pin Stecker
JP1: +5V oder +12Veinstellbar auf
Seriell Anschluss
den 9 Pin von S1
BESCHREIBUNG & TECHNISCHE DATEN :
PCI & PCI-X 3,3Volt & 5Volt bei 33Mhz
WIN 9x/2000/XP/Server 200x/Vista/7, (Linux vom OS)
1 x 9 Pin Seriell D-SUB Stecker, 1 x 25 Pin D-SUB Stecker
EX-43073, Treiber CD, Deutsche Anleitung
CE CE CE CE
/ FCC / RoHS / WEEE DE97424562 / WHQL
JUMPER EINSTELLUNG & ANSCHLÜSSE:
+5V JP3:
+12V
Dis
JP3 auf PCI
JP3 auf AUX = 5 oder +12V
1 +5V
Wenn JP3 auf AUX gestellt ist muss J4 mit dem Stromanschluss vom
2 GND
PC Netzteil verbunden werden! Bitte auf die richtige Polarität achten!
3 GND
4 +12V Achtung! Stecker nie bei eingeschaltetem PC ein oder ausstecken!
1
JP3: Umschaltung der
Spannung von
PCI-BUS auf
PC-Netzteil
JP4: Ein/Ausschaltung
Parallel-Port
J4: Anschluss vom
PC Netzteil für
+5V oder +12V
Spannung
Oxford OXuPCI952
+5V
+12V
PCI AUX
= +5 or +12V
kommt vom PCI BUS
kommt vom PC Netzteil
