Operation And Maintenance; Technical Parameters; Environment Protection - GRAPHITE 59G021 Betriebsanleitung

SCRAPING
Scrape soft materials (e.g. wood) at small angle and with small pressure.
Otherwise the scraper can damage the surface.
Unplug the power cord from mains socket before commencing any activities related to installation,
adjustment, repair or maintenance.
MAINTENANCE AND STORAGE
● It is recommended to clean the device immediately after each use.
●
Do not use water or other uids for cleaning.
●
The device should be cleaned using a dry piece of cloth or blown with compressed air of low pressure.
●
Do not use any cleaning agents nor solvents, since they may damage plastic parts.
●
Clean ventilation slots in the motor casing to prevent the device from overheating.
●
Working tools (apart from the delta grinding plate) should be cleaned using a wire brush.
●
If the power cord is damaged, it should be replaced with a power cord of the same parameters. This
should be performed by a qualied specialist or authorised service point.
●
In case of excessive sparking in the commutator, the condition of carbon brushes should be checked by
a qualied person.
●
The device should be always stored in a dry places, inaccessible to children.
REPLACEMENT OF CARBON BRUSHES
Replace immediately worn out (shorter than 5 mm), burnt or cracked motor carbon brushes. Always
replace both carbon brushes at a time.
Entrust replacement of carbon brushes only to a qualied person. Only original parts should be
used.
All defects should be repaired by service workshop authorized by the manufacturer.
RATED PARAMETERS
Parameter
Supply voltage
Input current frequency
Rated power
Idle oscillation speed
Oscillation angle
Pad dimensions
Protection class
Weight
Year of production
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure: Lp = 79,67 dB(A); K = 3 dB(A)
A
Sound power: Lw = 90,67 dB(A) ; K = 3 dB(A)
A
Vibration acceleration: a
h
Do not dispose of electrically powered products with household wastes, they should be utilized in
proper plants. Obtain information on wastes utilization from your seller or local authorities. Used up
electric and electronic equipment contains substances active in natural environment. Unrecycled
equipment constitutes a potential risk for environment and human health.

OPERATION AND MAINTENANCE

TECHNICAL PARAMETERS

Multi Purpose Tool
= 2,941 m/s K= 1.5 m/s
2 2

ENVIRONMENT PROTECTION

Value
230 V AC
50 Hz
300 W
15000-21000 min
2.8°
80 x 80 x 80 mm
II
1.45 kg
2014
