INSTALLATION AND REPLACEMENT OF SANDING PAPER
Sanding pad is equipped with hook-and-loop attachment system for quick and easy replacement of
sanding paper. Choose sanding paper with appropriate gradation depending on the processed material
and desired level of material removal. All types of sanding paper, abrasive cloths and polishing felt are
allowed.
● Put the sanding paper close to the sanding pad (1).
●
Press the sanding paper against the sanding pad (
●
To remove sanding paper, lift edge of it on one side and pull (
INSTALLATION OF WORKING TOOLS
● Pull out the lever for quick-fastening of accessories (3) (g. D).
●
Insert your working tool between both washers of the tool chuck, so that both openings match pins of
the upper washer.
●
To ensure operation in the most convenient and safe position for the user, working tools can be placed in
the tool chuck in any position provided that they match pins of the upper washer (g. B).
●
Your working tool should be inserted in such a manner, so that it points downward with its bent section.
●
Fasten the working tool in your selected position and lower the lever for quick-fastening of accessories (
Check that the tool is installed properly. Improperly or inaccurately installed working tools can slip
during operation and cause risk for the user.
DUST EXTRACTION
Dust of some materials may be hazardous to health, like paint coatings with lead additives, some
types of wood e.g. oak or beech or materials with asbestos. Therefore, we recommend use of external
dust extraction systems, good workplace ventilation and use of dust-mask with particle lter.
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the label of the tool.
Switching on – slide the switch (2) forward to position I (g. C).
Switching o – slide the switch (2) backward to position O.
Do not cover holes for motor ventilation in the tool body.
SPEED ADJUSTMENT
The rotational speed of the motor is adjusted by turning and setting the oscillation speed adjustment
dial (4) in a required position. This allows adjustment of working speed according to properties of your
workpiece. The oscillation speed adjustment ranges from 1 to 6.
The higher the value indicated by the oscillation speed adjustment dial (4), the higher the working speed
of the device is (g. E).
PRINCIPLES OF OPERATION
Oscillation frequency 15000-21000 rpm at 2.8° angle allows to work precisely in small areas and corners
with the power tool.
SAWING AND CUTTING
Use only undamaged working tools in good technical condition.
When sawing or cutting wood, bre board, wood-based materials etc. make sure they do not contain
foreign objects like nails, bolts etc before starting the task. Remove foreign objects or use proper
blade for removal. You can make plunge cuts only in soft materials like wood, gypsum boards and
alike.
Cutting ceramic tiles causes faster wear of working tool.
SANDING
Working eciency in surface sanding depends mainly on type and quality of sanding paper and pressure
applied for processing. Overpressure does not make sanding more ecient, it only causes faster wear of
sanding paper and may cause overheating of the power tool. Apply moderate and uniform pressure.
You can use tip or edge of the sanding pad to sand corners or edges in hardly accessible places.
1).

OPERATION / SETTINGS

13
g. A).
3).
