Magnets are used in the mask and headgear clips. Ensure the mask and headgear clips are kept at a proper distance from
any active medical implant to avoid possible effects from localized magnetic fields. The magnet will have a strength of
less than 400mT at a distance of 2 inches.
This mask has a non-transferable three month limited warranty for manufacturer's defects from the date of purchase by the
initial consumer. If a mask used under normal conditions should fail, Sleepnet will replace the mask. For additional information
about the Sleepnet Warranty, please visit http://www.sleepnetmasks.com/. Per EU MDR 2017/745, please report serious
incidents to manufacturer and EU Member State competent authority.
NOTE: The mask has a service life of 6 months.
Cleaning is recommended on a daily basis. Wash the mask and components in warm water using a mild soap such as Ivory
thoroughly after washing. Visually verify that the swivel elbow is not obstructed and allow the mask to air dry.
NOTE: Inspect mask and valve prior to each use. Replace the mask if parts are damaged or gel is exposed due to tear or
punctures.
NOTE: The gel cushion, although silky to touch, will not tear, leak or detach from the mask under normal use. Follow
recommended cleaning and maintenance protocols. The gel cushion is not indestructible. It will tear, cut and rip if
subjected to mishandling or abuse. Do not clean in a dishwashing machine. The warranty does not cover these types
of product failures. Therefore, please handle your new Mojo
Resistance to air flow at 50 L/min: 0.22 cm H
DEADSPACE VOLUME (mL approx.) Small 176 mL Medium 193 mL Large 206 mL Extra Large 220 mL
AAV Open to Atmosphere Pressure: 1.15 cm H
Resistance of the Anti-asphyxia valve in Single Fault Condition - Inspiratory: 1.20 cm H
Do not expose the mask to temperatures above 122°F (50°C).
Inspect mask daily or prior to each use. Replace the mask if parts are damaged, or if gel is exposed due to tears or
punctures.
Check the anti-asphyxia valve. With the positive pressure device turned off, verify that the valve flapper is positioned
so that room air can flow through the large opening in the valve (Figure 7a). Turn on the system; the flapper should
close, and system air should flow through the mask (Figure 7b). If the flapper does not close or does not function
properly, replace the mask. Do not block the opening on the anti-asphyxia valve. Ensure that the valve is not blocked
with secretions and that the flapper is dry.
1. Verify the mask is the right size. When using the sizing guide ensure mouth is slightly open. Line the top of the guide
to the bridge of the nose and select the smallest size that does not restrict the nose or mouth. The appropriate size may
be smaller than expected due to the design.
2. Lay headgear flat with light gray side facing up with the shorter straps at the top. Place mask in the center of the
headgear, and thread all 4 straps (Figure 1).
3. Unhook one or both magnetic clips from the mask. Seat the bottom cushion of the mask at the crease of the chin with
your mouth slightly open and tip the mask up to contact the nose (Figure 2). Turn the forehead adjustment screw so the
forehead pad lightly touches your forehead (Figure 6). The mask may sit lower on the nose than expected, depending
on facial features.
4. Slip the headgear over the head, hook the magnetic clips in place. (Figure 3). The headgear should be flat across the
back of the head.
5. Adjust lower headgear straps by using the hook and loop fastener tabs (Figure 4).
6. Adjust upper headgear straps: detach the hook and loop fastener tabs and pull straps forward to center mask over face.
Ensure headgear is centered by aligning the two straps. Then pull the straps back, adjust strap tension and affix tabs.
(Figure 5)
7. Turn the forehead pad adjustment screw to adjust tension until comfortable. If necessary, readjust top straps for a
comfortable fit.
8. If the mask is uncomfortable repeat steps 5-8.
NOTE:
I. If breathing through your nose or mouth is still constricted, contact your healthcare professional.
II. The mask should rest comfortably against the face. If there is excessive pressure on the bridge of the nose, loosen
the top straps, slowly turn the adjustment screw counter-clockwise to relieve the pressure on the bridge (Figure 6).
Then readjust the top straps and affix the tabs.
9. Attach the mask elbow to the device (CPAP, bi-level, ventilator) tubing; turn the device on and verify airflow through
the mask.
10. Gently press edges of the mask to change mask shape, create a comfortable fit, and reduce leaks.
11. If leaks are noticed around the chin or the cheeks, slightly tighten the bottom straps.
12. If leaks are noticed at the bridge of the nose, slowly turn the adjustment screw clockwise to slightly move the pad
away from the forehead (Figure 6). Then tighten the top straps slightly until leaks are eliminated. This may be done in
conjunction with molding the mask in the bridge area as described in Step 10 above.
6

GENERAL INFORMATION

CLEANING AND MAINTENANCE

TECHNICAL INFORMATION

O Resistance to air flow at 100 L/min: 0.45 cm H
2
O; AAV Close to Atmosphere Pressure: 1.55 cm H
2
BEFORE USE
MOJO 2 MASK FITTING INSTRUCTIONS
®
2 Full Face AAV Non Vented Mask with care.
®
O
2
2
O; Expiratory: 1.30 cm H
2
. Rinse
®
O
O
2
