CONSTRUCTA CD33686 Gebrauchs- Und Montageanleitung Seite 31

Slide the appliance up to at least halfway into the
2.
rails ​ ⁠ and guide the mains plug through the cut-out
​ ⁠ .
Slide the appliance as far as it will go into the cab-
3.
inet.
Fit the ducting.
4.
Note: Carefully position the duct in order to protect
5.
the appliance against scratches.
Gently push the duct against the fan box using both
hands ​ ⁠ and slide it back until the duct clicks into
place ​ ⁠ .
Gently push against the appliance with one hand
6.
and carefully open the glass panel.
Note: Ensure that the front of the appliance does
7.
not protrude over the front of the cabinet after it is
screwed in.
Tighten the threaded pins through the recess in the
rail hand-tight until the appliance is flush with the
cabinet.
Insert the covers.
8.
Remove the grease filters.
9.
Installation instructions en
31
