INK ROLLER REPLACEMENT

If printing is blurry even when the ink roller is in the
proper position, replace the roller.
Ink roller: Type EA-781R-BK (Black)
Type EA-781R-RD (Red)
WARNING:
APPLYING INK TO WORN INK ROLLER OR
USE OF UNAPPROVED INK ROLLER MAY
CAUSE SERIOUS DAMAGE TO PRINTER.
1) Set the power switch to OFF.
2) Remove the printer cover. (Fig. 1)
3) Remove the ink roller by turning it counterclock-
wise and pulling it upward. (Fig. 2)
4) Install the correct color new ink roller and press
it in the correct position. Make sure that the ink
roller is securely in place. (Fig. 3)
5) Put back the printer cover.
Red
7
Fig. 1
Fig. 2
Black
Fig. 3
