English (Original Instructions); Technical Data - DeWalt XR LI-ION DCD792 Bersetzt Von Den Originalanweisungen

EnGLIsh
TOOL CONNECT™ CORDLESS 13 mm DRILL/DRIVER, DCD792
TOOL CONNECT™ CORDLESS 13 mm DRILL/DRIVER/
HAMMERDRILL, DCD797
Congratulations!
You have chosen a D WALT tool. Years of experience, thorough
e
product development and innovation make D
most reliable partners for professional power tool users.

Technical Data

Voltage
Type
Battery type
Power output
No-load speed
1st gear
2nd gear
Impact rate
1st gear
2nd gear
Max. torque (hard/soft)
Chuck capacity
Maximum drilling capacity
Wood
Metal
Masonry
Weight (without battery pack)
Noise values and vibration values (triax vector sum) according to EN60745-2-1:
L (emission sound pressure level)
PA
L (sound power level)
WA
K (uncertainty for the given sound
level)
Drilling into metal
Vibration emission value a =
h, D
Uncertainty K =
Drilling into concrete
Vibration emission value a =
h, ID
Uncertainty K =
Screwdriving
Vibration emission value a =
h, D
Uncertainty K =
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN60745 and may be used to compare one tool with another. It
may be used for a preliminary assessment of exposure.
28
WALT one of the
e
DCD792 DCD797
V 18 18
DC
1 1
Li-Ion Li-Ion
W 460 460
min -1 0–550 0–550
min 0–2000 0–2000
-1
min — 0–9350
-1
min -1 — 0–34000
Nm 70/27 70/27
mm 1.5–13.0 1.5–13.0
mm 40 40
mm 13 13
mm — 13
kg 1.1 1.2
dB(A) 76 89
dB(A) 87 100
dB(A) 3 3
m/s 2 <2.5 <2.5
m/s 2 1.5 1.5
m/s 2 — 11.5
m/s 2 — 1.6
m/s 2 <2.5 <2.5
m/s 2 1.5 1.5

WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total working period.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of work patterns.
EC-Declaration of Conformity
Machinery Directive
Tool Connect™ Drill/Driver/Hammerdrill
DCD792, DCD797
D WALT declares that these products described under
e
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-1:2010,
EN60745-2-2:2010.
These products also comply with Directive 2014/30/EU,
2011/65/EU and 2014/53/EU. For more information, please
contact D WALT at the following address or refer to the back of
e
the manual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of D
Markus Rompel
Director Engineering
D WALT, Richard-Klinger-Straße 11,
e
D-65510, Idstein, Germany
23.03.2017
WARNING: To reduce the risk of injury, read the
instruction manual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
these symbols.
WALT.
e
