Multi-Base Setting

"Multi-Base" setting allows expanding coverage or lining capacity. When
nd rd th
adding 2 , 3 or 4 base station, using one of the handsets which registered
st
to the 1 base station (i.e. the handset with ID 11), followed by below
processes：
1. Press MENU right soft key followed by "7" to enter the
registration mode.
2. Press & hold the base station PAGE button for thress
seconds, the base station will emit the prompt sound
(also the base In Use LED is flashing).
3. Press digit "3" of handset to enter the Multi-Base
setting.
4. Select BS # 1
5. Repeat above step 1 ~ 4 to continuously add the 2
rd th
3 or 4 base station.
st
Re：The base ID for 1 base station is "10", for 2
rd
base station is "20", for 3 base station is "30", for
th
4 base station is "40".
Notes:
1. When initial setting the "Multi-Base", you have to select the BS #1
first, then followed the above steps to select 2
2. For synchronization mechanism, all handsets must be register again
before start using multi-base scenario. i.e. the initial handset ID with
1x must register to BS1, and the rest handsets must be registered to
nd rd th
2 , 3 or 4 base station respectively.
3. After all above processes, the "Multi-Base" is complete then.
nd
,
nd
nd rd th
, 3 or 4 base.
~45~

Call Manager

"Call Manager" feature allows two options：
1.One is the handset to be set to receive incoming calls or make outgoing
calls (2-way intercom, broadcast and transferred call are allowed). The
option is selectable by base station 1 to base station 4.
Re: "Call Manager" item will be hidden if Multi-Base function is disabled.
2.The other option is the handset to be set to access to available bases
automatically or manually.
st
For 1 option (Subscribe BS)：
1. Press MENU right soft key followed by
Call Settings mode.
Press "6" to select Call Manager.
Re: "Call Manager" item available or selectable only if
Multi-Base function is enabled.
2. Press 1 to set Subscribe BS.
Re：When entering the submenu of Subscribe BS,
the LCD will show the available bases which
already subscribed.
3. Press
or key to select the desired base station (#1~4), press
CHANGE left soft key to set the Subscribe BS ON/OFF.
4. If set the Subscribe BS ON, that means the handset is able to access
the line of the desired base station, so the handset is able to make
outgoing call or answer incoming call via the desired base station.
On the contrary, if set the Subscribe BS OFF, then the handset can't
access the line of the desired base station, so the handset isn't able to
make outgoing call or answer incoming call via the desired base station.
nd
For 2 option (BS Selection)：
1. Press MENU right soft key followed by
Call Settings mode.
Press "6" to select Call Manager.
4 to enter the
4 to enter the
