Illustration
 Twist out the cleaning rollers from the recessed
grip.
Illustration
 Clean the cleaning rollers under running water.
or
 Wash the cleaning rollers in the washing machine
up to 60°C.
ATTENTION
Do not use any soft detergents when cleaning in the
washing machine. This avoids causing damage to the
microfibres. It also preserves the high performance lev-
els of the cleaning rollers.
The cleaning rollers are not suitable for the tumble dry-
er.
ATTENTION
To avoid damaging the washing machine, we recom-
mend placing the rollers in a laundry net and loading the
washing machine with additional laundry.
Figure to
 Once cleaned, place the rollers on the cleaning sta-
tion storage and leave them to air dry.
 Drying time can be minimized by wringing out the
rollers beforehand.
 Also clean the floor head cover and waste water
tank if the device is not going to be used further.
 Clean the roller drive with a moist cloth.
Detergents and care products
ATTENTION
The use of unsuitable cleaning and disinfecting agents
can damage the appliance and will void the warranty.
Note
Add cleaning or disinfecting agent as required.
 When dosing the detergent and care product, fol-
low the manufacturer's dosage instructions.
 To prevent foaming, first fill the fresh water tank
with water then cleaning or disinfecting agent.
 To avoid exceeding the "MAX" fill level on the fresh
water tank, leave room for the cleaning or disinfect-
ing agent when filling with water.
Troubleshooting
Often, failures have simple causes and you can do the
troubleshooting yourself using the following overview. If
you are in doubt or if the failure is not listed here please
contact the authorized customer service.
Battery is not charging
 Charging plug/mains plug not correctly connected.
 Connect charging plug/mains plug correctly.
The device cannot be switched on
 Battery is empty.
 Charge the device.
 Check whether the charging cable is still plugged
into the device.
 Take out charging cable, operation is not possible
while charging cable is plugged in.
18
Lowermost LED flashes when the device is switched on
and does not start.
 Battery is empty.
 Charge the device.
All LEDs flash quickly simultaneously.
 The device has a motor blockage (e.g. due to ex-
cessive pressure on the rollers or through move-
ment into a wall/corner).
 Switch on/off the appliance again.
or
 Use of wrong or defective mains plug.
 Use original mains plug/replace defective mains
plug.
The three LEDs light up sequentially in a 1-second cy-
cle.
 Device too hot during use (e.g. when operating in
high ambient temperatures).
 Take a break and let the device cool down.
 If the device also switches off:
 Take a break and let the device cool down.
 The device can only be switched on again once it
has cooled down enough.
Rollers are too dry
Rollers are not being sufficiently moistened.
 Moisten the rollers by moving back and forth over
the same position.
The filter under the fresh water tank is incorrectly fitted
or not fitted at all.
 Ensure that the filter under the fresh water tank is
correctly fitted in the device. The foam with the yel-
low pin in the middle must point upwards.
Note
If the filter is not present, it can be ordered as a spare
part.
For information about accessories and spare parts,
please visit www.kaercher.com.
Appliance is not sucking up dirt
No water in the fresh water tank.
 Refill water
Fresh water tank does not fit properly in the device.
 Insert the fresh water tank so that it sits snugly in
the appliance.
Cleaning rollers missing or not fitted correctly.
 Fit the cleaning rollers or turn them onto the roller
holder up to the mechanical stop.
Cleaning rollers are contaminated or worn.
 Clean the cleaning rollers.
or
 Replace the cleaning rollers.
The detergent has been forgotten, an incorrect dosage
is being used or the incorrect detergent is being used
 Use only KÄRCHER detergent and be sure to use
the correct dosage.
Floor head cover not installed correctly
 Check that the floor head cover is correctly seated.
For this, remove the cover and then fit it back in
place.
– 11
EN
LED fault display
