OVERVIEW
8
1 DC connector
2 DC switch 1
3 DC connector
4 DC switch 3
5 WiFi stick port
6 Reserved terminal
7 AC cable - knockout seal
5

SCOPE OF DELIVERY

Inverterx1
QG0040_ASW75-110k-LT_EU_1122
1 2
9 10
inputs 1-6
（connected to DC switch 1）
inputs 13-16
（connected to DC switch 3
Mounting-bracket×1
WiFi stick×1
M4×9 Screws×6
3 4 5 6
11 12 13
8 Lock valve
9 DC connector inputs 7-12
10 DC switch 2
）
11 DC connector inputs 17-20
12 DC switch 4
13 RS485 Communication port
14 Reserved grounding - knockout seal
Handle×4 Lifting ring×2
(Optional) （Optional）
RS 485 COM plug×1 DC connector (pair)×16/20
M10×20 Bolt×2 Document packagex1
7
14
（Connected to DC switch 2）
（Connected to DC switch 4）
Expansion bolt×4
M5×12 Screws×2
