Symbol description

Do not use silicone containing acetic acid!
Maintenance (see page 67)
The check valves must be checked regularly according to EN 806-5 in accord-
ance with national or regional regulations (at least once a year).
Cleaning (see page 66)
Never use high pressure cleaners or steam cleaners to clean the fittings.
Factory preset (see page 64 / 65)
Runtime setting (see page 64)
10s
20s
30s
After adjusting the "hygiene flushing", the product must first be disconnected from
the power supply to be able to then make the adjustment of the "Runtime setting"
during the configuration phase. After disconnecting the power supply, it is
necessary to wait for 10 seconds before the power supply can be reconnected.
During this time, the capacitors discharge; otherwise the fitting remains in normal
mode.
Hygiene rinse (see page 65)
After adjusting the "runtime setting", the product must first be disconnected from
the power supply to be able to then make the adjustment to the "Hygiene flushing"
during the configuration phase. After disconnecting the power supply, it is
necessary to wait for 10 seconds before the power supply can be reconnected.
During this time, the capacitors discharge; otherwise the fitting remains in normal
mode.
Cleaning washbasin (see page 68)
After setting the parameters for the hygiene rinse or making a net reset, wait for
approx. 150 s before you can enable the "Permanent rinse" function.
Permanent rinse (see page 68)
After setting the parameters for the hygiene rinse or making a net reset, wait for
approx. 150 s before you can enable the "Permanent rinse" function.
Protected area (see page 62, Fig. 8)
0, 1, 2
Exchange battery (see page 67)
Spare parts (see page 69)
+
Special accessories (order as an extra)
Thermostatic mixer #15346000 (see page 69)
Dimensions (see page 63)
Flow diagram (see page 63)
Operation (see page 68)
Hansgrohe recommends not to use as drinking water the first half litre flowing from
the tap in the morning, after the hygiene rinse is enabled, or after prolonged
non-use. With enabled hygiene flushing, the fitting opens for 10 s every 24 h, 20 s
/ 48 h or 30 s / 72 h after it was last actuated.

Thermal disinfection

• Thermal disinfection pursuant to process sheet DVGW W 551 (≥ 70°C /
> 3 min) must only be carried out by qualified personnel.
• Risk of scalding with thermal disinfection!
• The cold water feed must be locked during thermal disinfection. Afterwards,
"Permanent rinse" can be enabled.
Net reset
A net reset causes the fittings to re-adjust.
• Interrupt the voltage supply to the fittings
• The fittings will re-adjust during the next 35 s. Do not reach into the field of
vision during this period of time..
• After a mains reset, all adjustments made at the fitting are retained.
Disposal of waste batteries and old Electrical &
Electronic Equipment (applicable in the European Union
and other European countries with separate collection
systems).
This symbol on the battery, the product or the packaging indicates that the battery
or the product shall not be treated as household waste. By ensuring the battery or
English
product are disposed of correctly, you will help prevent potentially negative
consequences for the environment and human health. The recycling of the
materials will help to conserve natural resources. To ensure that the battery or
product will be treated properly, hand over the product at end-of-life to the applica-
ble collection point for the recycling of batteries, electrical and electronic
equipment. For more detailed information about recycling of this product or
battery, please contact your local Civic Office, your household waste disposal
service or the shop where you purchased the product.
Test certificate (see page 72)
Assembly (see page 62)
7
