Setup 3: Lautsprechersimulation und Leistungsreduktion
Mischpult, AD-Wandler, Stagebox, etc.
3
+
–
DC 9V
DC POWER
2
1:
8-Ohm Verstärkerausgang über
verbinden.
2:
SOAK OUTPUT am Cabulator über
verbinden.
3:
D. I. OUTPUT am Cabulator über
Cabulator
Tip = (+)/ Ring = (–)
Tip = (+)/Sleeve = GND
Sleeve = Audio GND Only!
Developed by Tonehunter, Germany
www.tonehunter.com
Sound Performance Lab
www.spl.info
® The Tonehunter logo is a registered
trademark of Tonehunter Ltd.
® The SPL logo is a registered
trademark of SPL electronics GmbH
Transformer Bal.
Power Soak
Line Output
MADE IN GERMANY
Output
Connect to
IMPORTANT ADVICE
Connect to
Recording Device,
Speaker Cabinet
IN ORDER TO AVOID POSSIBLE DAMAGE OF
Stagebox, etc.
4 Ω to 16 Ω Load
YOUR GUITAR AMPLIFIER DO NOT SET ITS
MASTER VOLUME ABOVE 70%.
D.I. OUTPUT
REFER TO MANUAL FOR MORE INFORMATION.
SOAK OUTPUT
SERIAL NUMBER
mit SPEAKER IN am Cabulator
Lautsprecherkabel
mit 4- bis 16-Ohm-Gitarrenbox
Lautsprecherkabel
mit Line-Eingang des Folgegeräts verbinden.
Line-Kabel
Tip = (+)/Sleeve = GND
1
8Ω
Load Only !
Connect to Speaker
Out of Amplifier
Max: 100 Watts
SPEAKER IN
