SIDE SLEEPING CONFIGURATION (FASTENING THE CRIB
TO THE BED)
The crib can be fastened to the parents' bed (side sleeping
configuration).
WARNING - IMPORTANT FOR YOUR CHILD'S SAFETY.
This configuration is allowed only with beds that permit
compliance with all the conditions described in this
paragraph.
In particular, the lowered side of the crib must always be
positioned against the mattress of the parents' bed and the top
of the parents' mattress must be aligned with (or at most higher
than) the height of the containment barrier on the open side of
the crib (Fig.14-15). Moreover, the crib must be firmly fastened
to the structure of the parents' bed or to the mattress support
(mesh or slat sprung base).
WARNING: Check that the structure of the crib in side sleeping
configuration does not interfere with the parents' bed.
WARNING: When in use, make sure that the parent's bedsheets,
blankets, etc. do not invade the crib's space.
7. Open the side of the front barrier by completely opening the
zip fasteners "D1" (Fig. 16).
8. Next, press the release buttons "C7" next to the white circle
on the fabric and partially uncover the front barrier tube "A",
on one side first and then on the other (Fig. 17).
9. Once the tube has been completely uncovered on both
ends, move it under the base of the crib, rotate the supports
"C4" outwards and attach the tube to the supports (Fig. 18).
WARNING: If the tube connected below the crib creates an
interference between the crib and the parents' bed, disconnect
the tube from its support "C4" and remove it from the fabric,
so that the soft barrier comes into contact with the parents'
mattress. (Fig. 19-20-21)
WARNING: Use the crib with the bar lowered only in co-
sleeping configuration.
10. Put the crib against the parents' bed and check the height of
the crib compared to the parents' mattress.
WARNING: The top of the parents' mattress must be higher
than or the same as that of the containment barrier of the open
crib (Fig. 22). If this is not the case, use the height adjustment
system to achieve this condition on both sides.
WARNING: In side sleeping configuration, the crib's 2
legs must be set at the same height.
11. To fasten the crib to the parents' bed (side sleeping
configuration), use the pair of supplied straps "F".
12. Connect the forks "F1" to the straps with the buckles "C8"
located under the fabric lining on either side. Be sure that
the buckle "F3" is positioned above the belt strap (Fig. 23)
13. Next have the straps run from bottom to top "F" around
the frame of the parents' bed (Fig. 24) and connect the forks
"F2" to the buckles "F3" to form a loop (Fig. 25). Repeat
this operation on the other side as well. To make installation
easy, when fastening the buckles, always keep the crib
slightly away from the parents' bed.
14. At this point put the crib up against the parents' bed and
tighten the loop by pulling firmly on the straps "F" (Fig. 26).
Carry out this step first on one side and then on the other,
adjusting the straps until the crib is in firm contact with the
parents' mattress.
15. Push the mattress on the parents' bed up against the crib.
16. Act on the crib barrier so that it comes into contact with the
parents' mattress.
WARNING: Before each use, make sure that there is no space
between the parents' mattress and side of the crib. Otherwise
adjust the straps by pulling firmly until the required condition
is restored.
If, when fastening the crib to the parents' bed, the feet of the
crib do not fit under the parents' bed, the crib can be fastened
to the bed anyway by following the instructions above with the
added step of rotating the articulated feet "C5" when pressing
the crib up against the bed.
17. To rotate the front feet "C5" press the release button "C6"
and use one hand to rotate the feet of the crib inward (Fig.
27).
WARNING: Use the product with beds and/or mattresses with
straight sides only. Do not use the product with round beds
and/or mattresses or water mattresses.
WARNING: When the product is used in "Co-sleeping
configuration (fastened to the bed), " it must always be mounted
on the long side of the bed. DO NOT install the product at the
head or foot of the bed.
MAKING THE BED
The crib can be unfastened from the parents' bed when making
the bed. To do this, simply release the forks "F1" from the
buckles "C8" found under the fabric covering.
When fastening the crib again to the parents' bed, pull
the straps again to make sure that the crib is correctly and
securely fastened to the parents' bed. Make sure that all the
steps illustrated above, in the paragraph on "Co-sleeping
configuration (fastened to the bed)", have been completed.
CLOSING THE PRODUCT
The product can be closed for storage or transportation.
To close it:
18. If open, close the front barrier by attaching the detachable
tube to the appropriate position on the frame and close the
zip fasteners "D1".
19. Push down on the closure release levers "C3" and, while
holding the levers in the down position, energetically pull
up on the height adjustment buttons "C1" on either end
(Fig. 28-29). To be sure that the release has been activated,
the height adjustment button must nearly come into
contact with the articulation (Fig. 30).
20. Fold the frame by having it run downwards while
continuing to push frontwards (Fig. 31-32). The release
buttons described above must be pressed and held down
until the crib is completely folded.
21. To reopen the crib simply raise the frame upwards by taking
hold of the tubes (Fig. 33).
REMOVING THE COVER
For this operation, you will need:
22. To remove the mattress from the crib (Fig. 34).
23. To release the four straps with automatic buttons "D3"
located under the base of the crib (Fig. 35-36).
24. To open the zip fastener for the barrier "D1" (Fig. 16), release
the tube "A" (Fig. 17) and remove it (Fig. 37).
25. To open the zip fastener that runs along the top perimeter
"D2" (Fig. 38).
26. To remove the fabric (Fig. 39).
If the lining needs to be taken off of the mattress:
27. Carefully pull the wood panel and the mattress padding out
from the fabric cover.
To cover the crib and mattress complete the same steps in
reverse order.
WARNING: Covering or removing the fabric may take a few
minutes and must be carried out by an adult.
WARNING: When covering or removing the cover, take care
when handling the fabric parts to avoid accidental tears or
damage.

CARE AND MAINTENANCE

The crib and mattress have a resistant fabric lining that can be
removed completely and washed. To remove the fabric, follow
the instructions in the paragraph about "REMOVING THE
FABRIC."
