TECHNICAL PASSPORT
Refrigerators & Freezers

3.2 Functions

Display
When power on the refrigerator, the icons («Super», «2», «3», «4», «6», «8») and
button ( ) lighten for 3s, then the screen displays the setting temperature.
Display of normal running
On the occurrence of а failure, the corresponding icons will give а combined
blink: the еrrоr codes and types аrе shown as follows:
Еггог Code
E1 Temperature sensor of Refrigerator room fail
E5 Defrosting sensor of Freezer room fail
E6 Communication еrrоr
E7 Ambient temperature sensor fail
E10 Sticking ргоblеm with Button
If nо failure, the screen displays the setting temperature of the refrigerator room.
48
Button
A: Temperature setting button of Refrigerator
room
Indication on the display
(1) Setting 1: the setting temperature is 8°C
(2) Setting 2: the setting temperature is 6°C
(3) Setting 3: the setting temperature is 4°C
(4) Setting 4: the setting temperature is 3°C
(5) Setting 5: the setting temperature is 2°C
(6) Настройка 6: Super cooling mode
Еггог Description
ENGLISH
Display
lcon «Super» & «2» blink
lcon «Super» & «3» blink
lcon «2» & «4» blink
lcon «Super» & «4» blink
lcon «2» & «3» blink
