CONFIGURATION
LINKUP CONFIGURATOR APP
To configure the sensor, some parameters like the sensor type, its calibration or warning thresholds, must be
entered into the LinkUp gateway.
This is possible through the "Link Up Configurator" smartphone App, which can be downloaded free of
charge from the stores of both Android and iOS devices.
A simple explanation of the configuration process is also available as in-app instructions.
Thanks to the passive embedded NFC receiver, the LinkUp gateway can be configured, as described below,
without the need of a power supply.

SENSOR CONFIGURATION

9
LINK UP
CONFIGURATOR
1. Launch the "Link Up Configurator" App and read the current
configuration of the LinkUp device by "tapping" the smartphone
onto the LinkUp wireless area (indicated by the NFC symbol)
The readout is necessary before you can write new configurations
on the LinkUp.
NOTE: The antenna position on the smartphone depends on the
model.
Please refer to the smartphone manufacturer manual.
2. After the readout, the App will show the "CONFIGURATION
SUMMARY", which displays all the current settings of the device.
To see the exact sensor curve, that has been programmed on the
LinkUp Gateway before, press the button with the plus. This will
open a further table.
To modify the configuration, press the "Change Configuration"
button.
