CONFIGURATION

LINKUP CONFIGURATOR APP

To configure your system, some parameters must be calibrated through the LinkUp gateway. These
parameters are:
- number of engines, which should be analyzed through this gateway
the engine instances of those motors
-
- which alarms you want to receive on your dashboard
This is possible through the "LinkUp Configurator" smartphone App, which can be downloaded free of
charge from the stores of both Android and iOS devices.
A simple and detailed explanation of the configuration process is also available as in-app instructions.
Thanks to the passive embedded NFC receiver, the LinkUp gateway can be configured, as described below,
without the need of power supply.

GATEWAY CONFIGURATION

LINK UP
CONFIGURATOR
1. Launch the "Link Up Configurator" App and read the
actual configuration of the LinkUp device by
"tapping" the smartphone onto the LinkUp wireless
area (indicated by the red arrow).
NOTE: The antenna position on the smartphone
depends on the model.
Please refer to the smartphone manufacturer
manual.
