CONNECT TO THE NMEA 2000® NETWORK
Once the sensor installation is complete you can interface the
LinkUp gateway to the NMEA 2000® backbone through the
dedicated plug.
Please ensure to tighten the M12 connector by screwing it onto
its counterpart, so to preserve the water tightness.
A drop cable is not needed unless the total length of the LinkUp
device is not enough to reach the NMEA 2000® backbone. In
this case it is possible to extend the total length by using one of
the accessory drop cables.
Please note that NMEA 2000® does not allow drop cables
longer than 6 meters.
Refer to the NMEA 2000® standard for a proper network
design.
If power from the NMEA 2000® network is received, the green
LED on the LinkUp housing will start flashing (see "LED
notifications").

LIST OF SUPPORTED SENSORS

•
Fuel Level
•
Freshwater Level
•
Wastewater Level
•
Trim Level
•
Rudder Angle
•
Coolant Temperature
* The list of supported sensors may be updated at any time. Make sure to always use the latest version of the

LinkUp Configurator App.

8
SYSTEM INSTALLATION
•
Boost Pressure
•
Oil Temperature
•
Oil Pressure
•
Gear Oil Pressure
•
Gear Oil Temperature
•
Trim Tabs
