7. Manual programing on the device
7.1 LCD Display after switching on
Start up
Please wait ...
Encoder Modulator
192.168.1.225

7.2 Overview Main menu

The main menu appears after pressing the "Menu" button twice.
Use the arrow keys to control the menu.
Press "Enter" to confirm the settings.
"Menu" is used to change the menu.
Main menu
Status
Main menu
Input Settings
Main menu
Modulator
Main menu
Output Settings
Main menu
Network
Main menu
System
31
(Configuration is loaded and updated)
IP address of the device
Display of alarm messages and the running time of the
device
Adjustment of the input signals (SDI 1 Input 1, SDI 2 Input 2,
ASI IN)
Adjustments of the modulators Channel 1, Channel 2, Channel 3,
Channel 4
Selection of the transport streams for IP OUT and ASI OUT
Configuration of the NMS and data port
Backup/reload of settings, factory settings, version display,
password and device information
