DETAIL SANDER FDS-180
THE NUMBERS IN THE FOLLOWING TEXT
CORRESPOND WITH THE PICTURES AT PAGE 2
SAFETY AND OPERATING INSTRUCTIONS
For your own safety and for the safety of
others, please read these instructions carefully
before using this appliance. It will help you understand
your product more easily and avoid unnecessary risks.
Keep this instruction manual in a safe place for future
use.
TABLE OF CONTENTS:
1. Machine data
2. Safety instructions
3. Assembly
4. Use
5. Service & maintenance
1. MACHINE DATA
CONTENTS OF PACKING
1 Detail sander
1 Sand paper (grain 80)
1 Dust exhauster adaptor
1 User manual
1 Warranty card
1 Safety instructions
INTRODUCTION
The Detail sander FDS-180 is designed for dry sanding of
surfaces of wood, plastic and filler as well as for painter
surfaces. It is particularly suitable for working on
profiles, in corners or hard-to-reach areas.
TECHNICAL SPECIFICATION
Voltage
Frequency
Input power
Tool class
No load speed
Weight
Lpa (Sound pressure level)
Lwa (Sound power level)
Vibration
FEATURES
Fig. 1
1. On/off switch
2. Handle
3. Ventilating apertures
4. Sandpaper
5. Sanding-sole
Ferm Ferm
2. SAFETY INSTRUCTIONS
EXPLANATION OF SYMBOLS
In this manual and/or on the machine the following
symbols are used:
In accordance with essential applicable safety
standards of European directives
Class II machine – Double insulation – You don't
need any earthed plug.
Risk of damaging material and/or physical injuries
Shows presence of voltage
ELECTRICAL SAFETY
• Always check that the power supply corresponds to
the voltage on the rating plate.
• Immediately throw away old cables or plugs when
they have been replaced by new ones. It is dangerous
to insert the plug of a loose cable in the wall outlet.
• Only use an approved extension cable suitable for
the power input of the machine. The minimum
conductor size is 1,5 mm
always unwind the reel completely.
SPECIFIC SAFETY INSTRUCTIONS
• Contact or inhalation of dust coming free during
sanding (e.g. lead painted surfaces, woods and
metals), can endanger the health of operator and
bystanders. Always wear appropriate personal
equipment as a dust mask and use the dust bag during
sanding.
• Check that the switch is not in the "ON" position
before connecting the machine to the mains voltage.
• Always keep away the mains lead from moving parts
of the machine.
• Use safety glasses, especially when sanding above
your head.
3. ASSEMBLY
| 230V~
REPLACING WORN SANDING PAPER
| 50 Hz
Fig. 2
| 180 W
| II
Before assembly sanding paper always remove the
| 13000 r/min
plug from the mains.
| 1.2 kg
| 74.8 dB(A)
• The sandpaper (4) is fixed by Velcro fastener to
| 85.8 dB(A)
facilitate the replacement.
| 1.13 m/s 2
• Simply pull off the sanding paper
• Press the new one in the centre of the sand-sole (5)
Coarse sand-paper (grain 50) removes in general the
bigger part of the material and fine sand-paper (grain
120) is used for the finishing.
REPLACING THE SAND-SOLE
The sole has to be replaced when the Velcro has been
worn out.
2 . When using a cable reel
