CO NNECTI ONS PANE L AS SE M B LY
Attach the connections plate up to the bottom of the fan by inserting the set screw heads
into the key hole slots. Rotate them to place and tighten them to secure the plate.
LE D L IG HT PANE L AND L AM P SH ADE AS SE MB LY
1
Connect the single-pin plugs of the connections plate with the ones on the LED panel. The LED
panel is magnetized so it will be attached to the connections panel just by placing them together.
Note: While installing or removing the LED plate, please keep the insulation pads intact care-
fully. Turning the set screws over-tightly or fast will damage the insulation pads.
Screw the lamp shade back to the connections plate.
3
Connections panel
Connections panel screw

CEILING FAN WITH LED LIGHT

Single-pin plug
LED
2
4
