Quick Start Guide
RFID code lock
Item no. 2380478
Intended use
This product is designed to prevent unauthorised access to doors (e.g. in an office) and to
activate/disable alarm systems. The product enables to save up to 1000 users with different
transponders and user codes.
A valid access attempt activates a potential-free relay changeover contact (see contact rating
under "Technical data"). In this case, for example, a door opener or an alarm system can be
triggered.
The product is intended for vertical installation on a wall and is suitable for indoor and outdoor
use (IP 66).
For safety and approval purposes, do not rebuild and/or modify this product. Using the product
for purposes other than those described above may damage the product. In addition, improper
use can cause hazards such as a short circuit, fire or electric shock. Read the operating instruc-
tions carefully and store them in a safe place. Only make this product available to third parties
together with its operating instructions.
This product complies with statutory, national and European regulations. All company and pro-
duct names contained herein are trademarks of their respective owners. All rights reserved.
Explanation of symbols
The symbol with the lightning in the triangle is used if there is a risk to your health,
e.g., due to an electric shock.
The symbol with an exclamation mark in a triangle is used to highlight important
information in these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and tips on how to use the product.
Delivery content
• Code lock
• Fasteners (2x special screws with matching L key, 4x screw head stickers, mounting frame
with 4x screws and 4x dowels)
• Master transponder
• 1N4004 diode (for relay changeover contact)
• Quick start
• Programming guide
Installation, connection, getting started, programming and
operation
Detailed important instructions are downloadable from our website (enter the
item number to call up the page with product details).
Alternatively, follow the link www.conrad.com/downloads or scan the QR code.
Follow the instructions on the website.
There you will find the latest operating instructions for download.
Safety information
Damage caused due to failure to observe these instructions will void the
warranty. We shall not be liable for any consequential damage!
We shall not be liable for damage to property or personal injury caused by
incorrect handling or failure to observe the safety information! Such cases
will void the warranty/guarantee.
• This product is not a toy. Keep it out of the reach of children and pets.
• Protect the product from extreme temperatures, impacts, flammable gases, va-
pours and solvents. The code lock is suitable for indoor and outdoor installation
and use (IP66).
• Handle the product carefully. Jolts, impacts or a fall even from a low height may
damage the product. Do not place the product under any mechanical stress.
• Do not mount or connect the product when it is connected to a power supply.
• The contact rating for the changeover contact is specified in section "Technical
data" and must not be exceeded. Never switch the mains voltage, as this can
cause life-threatening electric shock!
• Always observe safety information and operating instructions for the other devices
(e.g. door opener, alarm system) to which the product is connected.
• If it is no longer possible to operate the product safely, stop using it and prevent
unauthorised use. Safe operation of the appliance can no longer be guaranteed if
it shows visible signs of damage, malfunctions, has been exposed to unfavourable
storage conditions or significant transport loads.
• For installations in industrial facilities, follow the accident prevention regulations
for electrical systems and equipment issued by the national safety organisation or
the corresponding national authority.
• Do not leave packaging material lying around carelessly. It may become a dan-
gerous toy for children!
• Maintenance, modifications and repairs must be carried out by a technician or a
specialist repair centre.
• If you are not sure how to operate the product correctly, or if you have any ques-
tions that are not answered in these operating instructions, contact us or another
specialist.
Disposal
Electronic devices are recyclable waste and must not be placed in household waste.
At the end of its service life, dispose of the product in accordance with applicable
regulatory guidelines.
Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declares that this
product conforms to Directive 2014/53/EU.
Click on the following link to read the full text of the EU Declaration of Conformity:
www.conrad.com/downloads
Enter the product item number in the search box. You can then download the EU
declaration of conformity in the available languages.
Technical data
Power supply . ....................................12 - 18 V/DC
Current consumption .........................standby < 30 mA
Frequency range ...............................124.6 - 125.4 kHz
Transmission power...........................11.62 dBm
Max. reading distance .......................approx. 3 cm
Data retention
in case of a power cut . .......................yes
Suitable transponders . .......................Commercially available EM transponders for frequency
125 kHz
Output . ...............................................Potential-free single-pole changeover contact (relay)
mode; default setting: 5 seconds)
Wiegand connection . .........................yes (output = 26-bit protocol, input = 26/34-bit protocol
with automatic recognition)
Memory cells .....................................990 user transponders or user codes
Mounting location ..............................indoors/outdoors
Protection class .................................IP66
Ambient conditions ............................Temperature -40 °C to +60 °C
Cable length ......................................approx. 25 cm
Dimensions . .......................................115 x 70 x 25 mm (H x W x D)
Weight ...............................................approx. 209 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2021 by Conrad Electronic SE.
Max. contact rating 24 V/DC, 2 A
Adjustable switching time (1 - 99 seconds or toggle
10 visitor transponders or visitor codes
