User manual / Bedienungsanleitung
6. Technical data:
Operating Voltage:
In- and Outputs:
Phono-unit:
Amplification:
Channel separation:
Distortion factor:
Input impedance/Capacity:
Output impedance:
Frequency response:
RIAA:
Headphone output:
Amplification:
Headphone impedance:
Connection:
Measurement unit:
Indication range:
Noise filter:
Dimensions: H x W x D
Weight:
* Provided that the warranty card is correctly completed and returned to Clearaudio, or your product is registered
online at https://clearaudio.de/en/service/registration.php, within 14 days of purchase.
Made in Germany
24V DC stabilised with power supply
Input: 100-240V~ / 47-63Hz
RCA-sockets, unsymmetrically
MM = 40dB, MC = 60dB
> 80dB
< 0,01% / 1kHz
MM = 47kOhms / 220pF
MC = 400Ohms / 220pF
100Ohms
20Hz – 70kHz /-3dB
RIAA +/- 0,5dB deviation
10dB
100 – 600 Ohm
6,3 mm-bushing
-50 till +6dB, accuracy +/-0.2dB
Gauge-measurement up to max. 19,99mV
from 200Hz / transconductance 12dB per
octave (valid only for right channel when unit is
in measurement use
47 x 102 x 190mm
azimuth optimizer: 750g
Power supply: 150g
