STAGE ALIGNMENT MENU

In a live scenario with different sources of amplification, like guitar
amplifiers on the stage, or natural sound sources like a battery, you
can virtually "align" the IG1T speakers, specifying the distance of the
sources in question, in metres or feet. This will allow to obtain a single
acoustic wavefront without any delays, in all the live scenarios where
this is required. The DSP will automatically delay the IG1T signal output,
increasing the performance effectiveness. To this purpose, after accessing
the STAGE ALIGNMENT menu:
1. Select and confirm the "DISTANCE" field
2. Select and confirm the desired distance value, with a range of 0-15 m
and a resolution of 20 cm.
3. Return to the initial screen by selecting the "HOME" symbol

SYSTEM DELAY MENU

If the IG1T speakers are used in environments requiring multiple
amplification stages replicated at different distances - for example when
they need to cover a particularly wide and long indoor environment,
with various sound obstacles, the signal output by the speaker can be
appropriately delayed, to ensure that the listener only perceives a single
apparent wavefront, at any point in the room.
To this purpose, after accessing the SYSTEM DELAY menu:
1. Select and confirm the "DELAY" field
2. Select and confirm the desired delay value, with a range of 0-126 ms in
terms of time or of 0-43.7 m / 0-143.4 ft (feet) in terms of distance
3. Return to the initial screen by selecting the "HOME" symbol
