SYSTEM COVERAGE MENU

For information about the functions contained in this menu, only displayed
if during SYSTEM CHECK the system has automatically detected 2 speakers,
also refer to paragraph "DIGITAL
EXAMPLES" section. This menu allows to change the emitted wave beam
and the relevant acoustic coverage, once the DSP has recognized the
installation of 2 IG1T speakers:
• UP +10° for an installation requiring an acoustic coverage from
the bottom up, with mounting on stand or subwoofer and with as
much inclination as possible.
• UP +5° to orientate the wavefront with a medium upward
inclination, with mounting on stand or subwoofer
• UP +2.5° to get an acoustic coverage with a slight upward
inclination.
• FAR 0° when you want a coverage getting as far as possible,
when speakers are installed in front of the auditorium, at the height
of the audience.
• DOWN -2.5° to be used to orientate the acoustic coverage
slightly downward (for example with the public not very far from the
speakers and flown installation).
• DOWN -5° for a directivity with a medium downward inclination
(for example with public close to the speakers and flown
installation).
• DOWN -10° to incline the acoustic coverage as downward as
possible (public very close to the speakers and flown installation).
