Installation
4.1.3

Fork sleeves (optional)

In order to connect the forklift truck and the fork sleeve, the forklift truck forks are inserted into the fork
sleeve.
The forks are locked either by using the locking screws, which are inserted through a hole in the forks, or by
using a chain or rope, which must be placed through the eyelet on the fork sleeves and around the fork carrier.
This connection must be made, otherwise the fork sleeve may slip off the forklift forks during forklift
handling. DANGER OF ACCIDENT!
4.1.4

Rotators (optional)

When using rotators, a free-wheel throttle valve must be installed.
In order to prevent a sudden speedup and stopping the rotational movements, as this may damage the
device within a short time.
53100347
1 Fork (of fork lift truck)
2 locking bolt
3 Fork sleeve
4 Chain/rope
13 / 25 GB
