If the GPS option has been installed, the determined position
data is stored together with the measurement results and
output when the device is read out.

4.13 Printing results

The device can be connected to the Dräger Mobile Printer BT
(see "Order list", page 21) via Bluetooth
Follow the Dräger Mobile Printer BT instructions for use.
Alternatively, the results can also be printed using the Dräger
Mobile Printer.
Follow the Dräger Mobile Printer instructions for use.

4.14 Exporting data

The data stored by the device can be exported and then
®
analyzed in Microsoft Excel, for example. (This function is
available from firmware version 2.0.0).
1. Connect the USB-C cable to the USB-C port of the device
and the USB port of a PC or laptop.
 The device turns on.
2. Log into the PIN 1 menu in the device menu and select
"Transfer mode".
 "Transfer mode" is shown on the device display.
3. Open Windows Explorer.
 The device is now displayed as a USB drive.
4. Open the path "USB drive\var\scenario_logs\BreathTest".
5. Select the CSV file.
6. Select Copy.
7. Select the desired drive and directory as the storage
location.
8. Select Save.
 The CSV file is saved.
9. Switch off the device using
5

Troubleshooting

An error message is displayed in the event of a device
malfunction. The number below the message is for service
purposes. If the error persists even after turning the device off
and on multiple times, contact authorized personnel, such as
DrägerService.
Error/Message Cause
Device does not (Rechargeable)
turn on. batteries are
empty.
Insufficient volume Subject is not
of breath/ blowing for long
invalid sample. enough or intermit-
tently.
Device out of tem- Device is too warm
perature range. or too cold.
Instructions for use |
Dräger Alcotest
®
to print results.
to exit "Transfer mode".
Remedy
Charge the
rechargeable bat-
tery or replace the
batteries.
Blow more strongly
and without inter-
ruption into the
mouthpiece/funnel.
If necessary, take a
manual or passive
breath sample.
Allow the device to
cool down or warm
up.
®
7000
Error/Message Cause
Measuring range
↑ ↑ ↑
(Measuring range exceeded. Resid-
exceeded). ual mouth alcohol
can distort the
measured values.
Insufficient volume Volume of breath
of breath. [Only for sample insufficient.
breath samples
using the mouth-
piece]
Sampling inter- Irregular exhala-
rupted. tion, abrupt cessa-
tion or inhalation.
Error number. Device error.
The red LED (Rechargeable)
flashes three times batteries are
in close succes- empty.
sion and the device Device is too warm
turns off. or too cold.
6

Maintenance

The device is delivered with default adjustment settings. The
date of the last adjustment can be recalled in the menu.
Dräger recommends that the device be adjusted once a year.
Have the device adjusted only by authorized persons, e.g.
DrägerService.
Comply with the national guidelines governing adjustment.
6.1

Charging the rechargeable battery

WARNING
Risk of burns and electric shock!
The use of power supply units that have not been approved
by Dräger can cause burns and electric shocks when
charging the rechargeable battery.
► Use only the power supply unit specified in the order list.
● Connect the USB-C cable to the USB-C port of the device
and a USB charger.
 The rechargeable battery will charge.
| en
Troubleshooting
Remedy
A wait time of at
least 15 minutes
after alcohol was
last consumed
must have
elapsed. To repeat,
press the but-
ton.
Repeat the breath
sample after press-
ing the button.
If necessary, take a
manual or passive
breath sample.
Repeat the breath
sample after press-
ing the button.
If necessary, take a
manual or passive
breath sample.
Turn the device off
and then back on.
If the error persists,
contact DrägerSer-
vice or your dealer.
Charge the
rechargeable bat-
tery or replace the
batteries.
Allow the device to
cool down or warm
up.
