UK
Using extension cables
Only use an approved extension cable suitable for the power input of the machine. The minimum
conductor size is 1.5 mm
2
. When using a cable reel always unwind the reel completely.
3.
INSTALLATION
The grinder must be firmly bolted to a workbench. The length of the fixing bolts will depend on
the thickness of the workbench. If the workbench is made of steel, it is advisable to use a
wooden block or plank between the grinder and the bench, to insulate it and prevent vibration.
Assembly and adjustment of eye shield bracket and eye shield
Fig. C
The eye shield bracket and eye shield should only ever be assembled/adjusted
with the grinding wheel stationary, and the machine disconnected from the power
supply.
•
Fix the eye shield bracket (4) with attached eye shield to the grinding wheel cover, using the
screw provided (A).
•
Set the eye shield bracket at the correct height. The clearance (B) between the wheel and
the eye shield bracket should be 1 to 1.5 mm.
•
Next tighten the screw (A) firmly.
•
Position the eye shield to give maximum protection when working.
•
Always wear safety glasses.
Fitting and adjusting tool rest
Fig. C
The tool rest should only be adjusted when the grinding wheel is completely statio-
nary, and the machine is disconnected from the power supply (the wall socket).
•
Fit the tool rest as shown in Fig. C.
•
Fix it as tightly as possible in position, with a maximum clearance (C) of 1 – 1.5 mm
between the tool rest and the grinding wheel.
Replacing the grinding wheel
Fig. D
Required tools:
•
19 mm Spanner
•
8 mm Spanner
•
Screwdriver
Only ever replace the grinding wheel when the motor is at a standstill and the
power is completely disconnected.
6
CE
Vi erklærer herved, udelukkende på eget ansvar, at dette produkt opfylder følgende standarder
EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3, EN61029-1, EN61029-2-4
Fra 01-10-2005
ZWOLLE NL
W. Kamphof
Quality department
Det er vores hensigt til stadighed at forbedre vores produkter, og vi forbeholder os derfor til
enhver tid retten til at ændre produktspecifikationerne uden forudgående varsel.
Ferm BV • Lingenstraat 6 • 8028 PM • Zwolle, Holland
Ferm
Ferm
KONFORMITETSERKLÆRING (DK)
eller standardiserede dokumenter:
i overenstemmelse med direktivreglerne
98/37/EEC, 73/23/EEC, 89/336/EEC
DK
79
