Check before operation

CAUTION
• Check that the air filters are installed.
• Check that the air outlet or inlet of the outdoor unit is not blocked.

Cleaning the air filter

Clean the air filters every 2 weeks.
If the air filters are covered with dust, the performance of the air
conditioner will deteriorate.
Clean the air filters as often as possible.
1
Open the air inlet grille.
Lift the air inlet grille up to the horizontal position.
2
Take hold of the left and right handles of the air filter and lift
it up slightly, then pull it downward to take it out from the
filter holder.
3
Remove the filters.
4
Use a vacuum cleaner to remove the dust from the filters or
wash them with water. If you wash the air filters, dry them in
the shade.
5
Insert the upper portion of the air filter aligning right and left
edges on the indoor unit until correctly positioned.
6
Close the air inlet grille.
* If the filter lamp on the indoor unit is indicated, push the FILTER
button on the remote controller or the TEMPORARY button on
the indoor unit to turn off the lamp.
10
FAN ONLY Operation
Air filter
Filter holder
Filter holder
