STANDALONE MODE CCT PRESET
Starting from the main display, press MENU to enter the main menu. Using and , select the
menu item Stand Alone and confirm with ENTER, then select CCT Preset and confirm once
again with ENTER. Now use
ENTER. The desired Preset (Warm White – Cold Daylight, User Color 1 – User Color 4) can only be
selected with and . Confirm your selection with ENTER. Set the desired brightness (Dimmer)
and strobe (Strobe) using
correspond to those in channel 2 of the DMX table D4CH Strobe CCT.
Menu
DMX Address
DMX Mode
DMX Delay
Stand Alone
Slave
Settings
System Info
PLAYBACK LOOP STANDALONE MODE
Starting from the main display, press MENU to enter the main menu. Using and , select the
menu item Stand Alone, confirm with ENTER, then select Playback Loop and confirm again
with ENTER. Now use
for playback and confirm again. All four loops can be edited individually (Main Menu -> Stand
Alone -> Edit Loop). A delay time for slave units can also be set (Loop Delay).
Menu
DMX Address
DMX Mode
DMX Delay
Stand Alone
Slave
Settings
System Info
EDITING USER PRESETS (Edit User Colour)
The four user presets available in the standalone mode CCT Preset can be edited individually.
Starting from the main display, press MENU to enter the main menu. Using
menu item Stand Alone, confirm with ENTER, then select Static and confirm once again. Now
use and to select the desired preset and confirm with ENTER. You can now create an individ-
ual colour mix of CW, WW and Amber with values ranging from 0 to 100 each (select colour with
and , confirm with ENTER, change value with
16
and to select the currently activated preset and confirm with
and . Confirm all entries with ENTER. The strobe effect values
Stand Alone CCT Preset
Static Warm White
CCT Preset
Playback Loop
Edit User Color
Edit Loop
and to select Loop, confirm, then select one of the four available loops
Stand Alone Playback Loop
Static
CCT Preset Loop Delay
Playback Loop
Edit User Color
Edit Loop
Dimmer
Strobe
Loop Selection of the
Loop
loops
Loop Sets the delay
Delay time for slave
units
and , confirm with ENTER).
Loop 1
|
Loop 4
0.0-2.0 s
and , select the
