6 Parts overview and delivery content -
windmeter
C
2
3
12
Illustration 2: All parts of the windmeter
1 Wind cups
3 Bottom housing part
5 LED Status indicator (flashes dur-
ing data transmission)
7 Battery compartment
9 Battery compartment cover
11 Thick nut
13 Mounting base (for vertical and
horizontal assembly of the
mounting rod)
15 Thin partly threaded screw
17 Rubber pads
1
6
4
10
14
13
5 7
9
11
3
12
17
15
16
2 Upper housing part
4 Thick fully threaded screw
6 Radiation protection slats
8 RESET button (reset all settings)
10 Rod clamp on bottom housing
part
12 Mounting rod
14 Thin nut
16 Tube clamp (counterpart)
8
4
11
4
