The following variants are available:
BASIC
Due to the built-in, clear PMMA front panel, the BASIC
version is recommended for ceiling heights of 4 m and
above.
[A] Version EM (luminaire with emergency light function):
ALDEBARAN® SMARTLINE RP110 LED EM /
ALDEBARAN® SMARTLINE RP72 LED EM /
ALDEBARAN® SMARTLINE RP72 LED EM SPEZIAL
C
[C] Version DIM (luminaire with DIM function):
ALDEBARAN® SMARTLINE RP72 LED DIM)
[a] Supply line with molded plug
INFORMATION!
• The protective film on the front pane may need to be removed before using the luminaire.
For luminaires with integrated rechargeable battery
• The rechargeable battery is partially charged upon delivery. Charging takes place after the luminaire has been
switched on. The full lighting duration of the luminaire is only available to you after it has been charged. Please
note the specified charging time in the technical data.

Model differences

COMFORT
Due to the built-in, milky PMMA front panel, the
COMFORT version is suitable for lower ceiling heights.

Controls

[B] Version DIM (luminaire with DIM function):
ALDEBARAN® SMARTLINE RP110 LED DIM
A
B
(A) LED display
(B) TEST
(C) Button (EM OFF)
E
(D) Rotary potentiometer
(E) Button (ON / OFF / DIM)
[b] Supply line with fitted plug (IP68)

Before initial operation

D
