By-Pass assembly for one heat pump
Key
By-Pass assembly for more than one heat pump
Key
The filter located upstream of the heat pump must be regularly cleared so that the water in
the system is clean, thus avoiding the operational problems associated with dirt or clog-
ging in the filter.
3. Installation
TOWARDS THE POOL
Automated treatment
system
Filtration + Pump
FROM THE POOL
Half-open valve
TOWARDS THE POOL
Automated treatment
system
Filtration + Pump
FROM THE POOL
Half-open valve
15
POOL
Open valve
POOL
Open valve
