Technical Data; Specified Conditions Of Use; Residual Risk - Milwaukee M12 FDSS Originalbetriebsanleitung

14

TECHNICAL DATA

Type
Production code
Battery voltage
No-load speed 1/2/3/4
Orbital travel diameter
Dimensions of grinding plate
Weight according EPTA-Procedure 01/2014
(Li-Ion 2,0 Ah ... 6,0 Ah)
Recommended Ambient Operating Temperature
Recommended battery types
Recommended charger
Noise information: Measured values determined according to EN 62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level / Uncertainty K
Sound power level / Uncertainty K
Wear ear protectors!
Vibration information: Vibration total values (triaxial vector sum) determined
according to EN 62841
Vibration emission value a / Uncertainty K
h
WARNING!
The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test given in
EN 62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration and noise emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched off or when it
is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
IIdentify additional safety measures to protect the operator from the effects of vibration and/or noise such as: maintain the tool and the
accessories, keep the hands warm, organization of work patterns.
WARNING!
Read all safety warnings, instructions,
illustrations and specifications provided with this power tool. Failure
to follow all instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Never reach into the danger area of the machine when it is running.
Chips and splinters must not be removed while the machine is
running. Use protective equipment. Always wear safety glasses
when working with the machine. The dust produced when using
this tool may be harmful to health. Do not inhale the dust. Use a
dust absorption system and wear a suitable dust protection mask.
Remove deposited dust thoroughly, e.g. with a vacuum cleaner.
Immediately switch off the machine in case of considerable
vibrations or if other malfunctions occur. Check the machine in order
to find out the cause.
The workpiece must be fixed if it is not heavy enough to be steady.
Do not let any metal parts enter the airing slots - danger of short
circuit!
WARNING! To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
or charger in fluid or allow a fluid to flow inside them. Corrosive or
conductive fluids, such as seawater, certain industrial chemicals,
and bleach or bleach containing products, etc., Can cause a short
circuit.
Only use original Milwaukee sanding and polishing tools with
selfadhesive hook&loop fastening.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Use only System M12 chargers for charging System M12 battery
packs. Do not use battery packs from other systems.
M12 FDSS
Oscillating sander
4914 26 01 XXXXXX MJJJJ
12 V ⎓
0-8000 / 0-10000 / 0-12000 / 0-14000 min
1,5 mm
88,8 x 63,5 mm
0,76 ... 1,00 kg
-18 ... +50 °C
M12B...
C12C; M12C4; M12-18...
64,69 dB (A) / 3 dB (A)
75,69 dB (A) / 3 dB (A)
4,3 m/s / 1,5 m/s
2

SPECIFIED CONDITIONS OF USE

The sander can be used for sanding wood, plastic, metal, filler and
painted surfaces.
Do not use the product in any way other than those stated for
intended use.

RESIDUAL RISK

Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise in use and the operator should pay special
attention to avoid the following:
• Injury caused by vibration. Hold the product by designated
handles and restrict working time and exposure.
• Exposure to noise can cause hearing injury. Wear ear protection
and limit exposure.
• Injury due to flying debris. Wear eye protection, heavy long
trousers, gloves and substancial footwear at all times.
• Inhalation of toxic dusts.
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after use.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and
away from moisture
ENGLISH
-1
2
15
