Spezifikationen
gsm dtmf sms master pin show
gsm phonebook check set {OFF=0|ON=1}
gsm phonebook check show
gsm freecall enabled set {OFF=0|ON=1}
gsm freecall enabled show
gsm admin only set {OFF=0|ON=1}
gsm admin only show
gsm sms response set {OFF=0|ON=1}
gsm sms response show
gsm sms error set {OFF=0|ON=1}
gsm sms error show
gsm sms signal set {OFF=0|ON=1}
gsm sms signal show
gsm port name set {OFF=0|ON=1}
gsm port name show
gsm sms autosync set {OFF=0|ON=1}
gsm sms autosync show
gsm call voice enabled set {OFF=0|ON=1}
gsm call voice enabled show
gsm call dtmf enabled set {OFF=0|ON=1}
gsm call dtmf enabled show
gsm phonebook {1..20} name set "{name}"
gsm phonebook {1..20} name show
gsm phonebook {1..20} phonenum set
"{phone_num}"
gsm phonebook {1..20} phonenum show
gsm phonebook {1..20} port set {port_num}
gsm phonebook {1..20} port show
gsm phonebook {1..20} action set {NONE=0|
GSM_TOGGLE=1|GSM_ON=2|GSM_OFF=3|
GSM_RESET=4|GSM_ONOFF1S=5|
GSM_ONOFF5S=6|GSM_OFFON1S=7|
GSM_OFFON5S=8}
gsm phonebook {1..20} action show
gsm imsi set "{num}"
gsm imsi show
gsm sms email gateway set "{phone_num}"
gsm sms email gateway show
gsm balance name set "{name}"
gsm balance name show
gsm balance action set "{text}"
gsm balance action show
http
http server set {HTTP_BOTH=0|HTTPS_ONLY=1|
HTTP_ONLY=22|HTTPS_REDIR=3}
http server show
http port set {ip_port}
http port show
http portssl set {ip_port}
http portssl show
http tls mode set {TLS12=0|TLS13_12=1|
TLS13=2|TLS13_12_11=3}
http tls mode show
http ajax enabled set {OFF=0|ON=1}
http ajax enabled show
http passwd enabled set {OFF=0|ON=1}
http passwd enabled show
http passwd local set {OFF=0|ON=1}
http passwd local show
http passwd radius set {OFF=0|ON=1}
http passwd radius show
http passwd user set "{passwd}"
http passwd admin set "{passwd}"
http passwd hash user set "{passwd}"
http passwd hash admin set "{passwd}"
input
input {port_num} state show
input all state {MODE0=0|MODE1=1|MODE2=2}
Expert Net Control 2111/2191
shows master pin for port changes
only allow access to calls that correspond to
phonebook entries
shows if phonebook change enabled
enable functions associated with incoming phone
numbers
show if freecall enabled
only allow caller actions from the admin
phonenum
show if caller actions limited to admin phoennum
send a SMS respone for every SMS cmd
show if a SMS respone is sent for every SMS cmd
send a error SMS for a defective incoming SMS
show if error SMS are sent for defective incoming
SMS
send status messages when signal quality
changes
shows if status messages are sent for signal
quality changes
enable that complete port names are sent via
SMS
show if complete port names are sent
get date and time from GSM after power-up
show if autosync is enabled
enable voice samples when a call is coming in
show if voice samples are enabled
allow DTMF tones in voice steering
show if DTM tones are enabled
set name for phonebook entry
show name for phonebook entry
set number for phonebook entry
show number for phonebook entry
set power port num for freecall actions
set power port num for freecall actions
set freecall action
show freecall action
enter your IMSI number
show entered IMSI number
set number of SMS to email gateway
show number of SMS to email gateway
enter word that names prepaid balance
show prepaid balance string
enter provider query for prepaid balance
show prepaid balance provider query
enters cmd group "http"
sets accepted connection types
shows accepted connection types
sets http port
shows http port
sets https port
shows https port
restricts TLS mode
shows TLS mode restriction
enables ajax autorefresh on/off
shows if ajax autorefresh enabled
enables http password on/off
shows if http password enabled
enables local login on/off
shows if local login enabled
enables login for RADIUS on/off
shows if RADIUS login enabled
sets http user password
sets http admin password
sets hashed http user password
sets hashed http admin password
enters cmd group "input"
shows input state
shows input state of all ports in 3 different view
4
98
