Spezifikationen
mqtt {broker_idx} topic set "{name}"
mqtt {broker_idx} topic show
mqtt {broker_idx} console enabled set {OFF=0|
ON=1}
mqtt {broker_idx} console enabled show
mqtt {broker_idx} device data timer set
{num_secs}
mqtt {broker_idx} device data timer show
port
port {port_num} state set {OFF=0|ON=1}
port {port_num} state show
port all state set "{port_list}" {OFF=0|ON=1}
port all state {MODE0=0|MODE1=1|MODE2=2}
show
port all set {OFF=0|ON=1|OFF_REV=2|
ON_REV=3}
port restart all set {REINIT=0|
OFF_REV_REINIT=1,OFF_REINIT=2}
port {port_num} reset
port {port_num} toggle
port {port_num} batch set {OFF=0|ON=1} wait
{num_secs} {OFF=0|ON=1}
port {port_num} batch cancel
port {port_num} label set "{name}"
port {port_num} label show
port {port_num} initstate coldstart set {OFF=0|
ON=1|REMEMBER=2}
port {port_num} initstate coldstart show
port {port_num} initstate delay set {num}
port {port_num} initstate delay show
port {port_num} repowerdelay set {num}
port {port_num} repowerdelay show
port {port_num} resettime set {num}
port {port_num} resettime show
port {port_num} watchdog enabled set {OFF=0|
ON=1}
port {port_num} watchdog enabled show
port {port_num} watchdog mode set {OFF=0|
PORT_RESET=1|IP_MS=2|IP_MS_INV=3}
port {port_num} watchdog mode show
port {port_num} watchdog type set {WD_ICMP=0|
WD_TCP=1}
port {port_num} watchdog type show
port {port_num} watchdog link down set {OFF=0|
ON=1}
port {port_num} watchdog link down show
port {port_num} watchdog host set "{dns_name}" sets port watchdog host target
port {port_num} watchdog host show
port {port_num} watchdog port set {ip_port}
port {port_num} watchdog port show
port {port_num} watchdog pinginterval set {num}
port {port_num} watchdog pinginterval show
port {port_num} watchdog pingretries set {num}
port {port_num} watchdog pingretries show
port {port_num} watchdog retrybooting set
{OFF=0|ON=1}
port {port_num} watchdog retrybooting show
port {port_num} watchdog bootretries set {num}
port {port_num} watchdog bootretries show
radius
radius {PRIMARY=0|SECONDARY=1} enabled
set <off=0/on=1>
radius {PRIMARY=0|SECONDARY=1} enabled
show
radius {PRIMARY=0|SECONDARY=1} server set
"<dns_name>"
radius {PRIMARY=0|SECONDARY=1} server
show
radius {PRIMARY=0|SECONDARY=1} password
set "{passwd}"
radius {PRIMARY=0|SECONDARY=1} password
hash set "{passwd}"
radius {PRIMARY=0|SECONDARY=1} auth
timeout set {num_secs}
Expert Net Control 2111/2191
sets topic prefix
shwos topic prefix
permit console cmds
shows if console cmds allowed
sets telemetry interval
shows telemetry interval
enters cmd group "port"
sets port to new state
shows port state
sets several ports in one cmd - e.g. port all state
set "1,3,5" 1
shows all port states in 3 different view modes
switch all ports on/off forward or reverse
reinit coldstart sequence (optional first all off)
start reset sequence for port
toggles port
starts batch mode for port
cancels batch mode
sets port label name
shows port label name
sets port coldstart initialization
shows port coldstart initialization
sets port init delay
shows port init delay
sets port repower delay
shows port repower delay
sets port reset duration
shows port reset duration
sets port watchdog to on/off
shows port watchdog state
sets port watchdog mode
shows port watchdog mode
sets port watchdog type
shows port watchdog type
sets if watchdog active when eth link down
shows if watchdog active when eth link down
shows port watchdog host target
sets port watchdog TCP port
shows port watchdog TCP port
sets port watchdog ping interval
shows port watchdog ping interval
sets port watchdog ping retries
shows port watchdog ping retries
sets port watchdog retry booting to on/off
shows port watchdog retry booting state
sets port watchdog retry boot timeout
hows port watchdog retry boot timeout
enters cmd group "radius"
enables radius client
show if radius client enabled
sets radius server address
shows radius server address
sets radius server shared secret
sets radius server crypted shared secret
sets server request timeout
4
92
