Spezifikationen
enc2111InputName
enc2111State12V
enc2111State3V
enc2111POE
enc2111PwrSupplyIndex
enc2111PwrSupplyStatus
epc2111NTPTimeValid
epc2111NTPUnixTime
epc2111NTPLastValidTimestamp
enc2111SensorIndex
enc2111TempSensor
enc2111HygroSensor
enc2111InputSensor
enc2111AirPressure
enc2111DewPoint
enc2111DewPointDiff
enc2111ExtSensorName
4.6.2
Geräte MIB 2191
Es folgt eine Tabelle aller gerätespezifischen OID's die über SNMP angesprochen wer-
den können. Bei der numerischen OID Darstellung wurde der Präfix
"1.3.6.1.4.1.28507" zur Gude Enterprise OID aus Platzgründen bei jedem Eintrag in
der Tabelle weggelassen. Die komplette OID würde daher z.B.
"1.3.6.1.4.1.28507.61.1.1.1.1" lauten. Man unterscheidet in SNMP bei OID's zwischen
Tabellen und Skalaren. OID Skalare haben die Endung ".0" und spezifizieren nur einen
Wert. Bei SNMP Tabellen wird das "x" durch einen Index (1 oder größer) ersetzt, um
einen Wert aus der Tabelle zu adressieren.
Name
enc2191TrapCtrl
enc2191TrapIPIndex
enc2191TrapAddr
enc2191portNumber
enc2191PortIndex
enc2191PortName
enc2191PortState
enc2191PortSwitchCount
Expert Net Control 2111/2191
Input state of device
.60.1.5.6.2.1.32.x
A textual string containing name of the Input
.60.1.5.7.1.0
Show state of internal 12V
.60.1.5.7.2.0
Show state of internal 3.3V
.60.1.5.10.0
signals POE availability
.60.1.5.13.1.1.x
Index of Power Supply entries
.60.1.5.13.1.2.x
shows status of the Power Supply 1 = fst, 2 = snd etc.
.60.1.5.15.1.0
Show if valid Time is received
.60.1.5.15.2.0
show received NTP time as unixtime (secs since 1 January 1970)
.60.1.5.15.3.0
show seconds since last valid NTP timestamp received
.60.1.6.1.1.1.x
None
.60.1.6.1.1.2.x
actual temperature
.60.1.6.1.1.3.x
actual humidity
.60.1.6.1.1.4.x
logical state of input sensor
.60.1.6.1.1.5.x
actual air pressure
.60.1.6.1.1.6.x
dew point for actual temperature and humidity
.60.1.6.1.1.7.x
difference between dew point and actual temperature (Temp -
DewPoint)
.60.1.6.1.1.32.x
A textual string containing name of a external Sensor
OID
Description
.61.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.61.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.61.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.61.1.3.1.1.0
The number of Relay Ports
.61.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.61.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.61.1.3.1.2.1.3.x
current state of a Relay Port
.61.1.3.1.2.1.4.x
The total number of switch actions ocurred on a Relay Port. Does not
count switch commands which will not switch the ralay state, so just real
relay switches are displayed here.
OCTETS RW
INTEGER RO
INTEGER RO
INTEGER RO
Integer32 RO
INTEGER RO
INTEGER RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
INTEGER RO
Integer32 RO
Integer32 RO
Integer32 RO
OCTETS RW
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
© 2021 GUDE Systems GmbH
