extsensor {port_num} {sen_type} {sen_field}
events type set
"{EVT_SYSLOG=0,EVT_SNMP=1,EVT_EMAIL=2
,EVT_SMS=3,EVT_GSMEMAIL=4,EVT_BEEPER
=5,EVT_DISPLAY=6,EVT_CONSOLE=7,EVT_M
QTT=8}"
extsensor {port_num} {sen_type} {sen_field}
events type show
extsensor {port_num} {sen_type} {sen_field}
phonebook sms events set "{1..20}"
extsensor {port_num} {sen_type} {sen_field}
phonebook sms events show
extsensor {port_num} {sen_type} {sen_field}
maxval set {num}
extsensor {port_num} {sen_type} {sen_field}
maxval show
extsensor {port_num} {sen_type} {sen_field}
minval set {num}
extsensor {port_num} {sen_type} {sen_field}
minval show
extsensor {port_num} {sen_type} {sen_field} hyst
set {num}
extsensor {port_num} {sen_type} {sen_field} hyst
show
extsensor {port_num} {sen_type} {sen_field}
publish mode set {NONE=0|INTERVAL=1|
DELTA=2|INTERV_DELTA=3}
extsensor {port_num} {sen_type} {sen_field}
publish mode show
extsensor {port_num} {sen_type} {sen_field}
publish mqtt retain set {OFF=0|ON=1}
extsensor {port_num} {sen_type} {sen_field}
publish mqtt retain show
extsensor {port_num} {sen_type} {sen_field}
publish timer set {num_secs}
extsensor {port_num} {sen_type} {sen_field}
publish timer show
extsensor {port_num} {sen_type} {sen_field}
publish delta set {float}
extsensor {port_num} {sen_type} {sen_field}
publish delta show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port set {port_num}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state set {OFF=0|ON=1|
DISABLED=2}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state show
extsensor period set {24H=0|12H=1|2H=2|1H=3|
30MIN=4}
extsensor period show
gsm
gsm enabled set {OFF=0|ON=1}
gsm enabled show
gsm pin set "{pin_num}"
gsm pin show
gsm phonenum set "{phone_num}"
gsm phonenum show
gsm admin sms set "{phone_num}"
gsm admin sms show
gsm admin sms enabled set {OFF=0|ON=1}
gsm admin sms enabled show
gsm admin email enabled set {OFF=0|ON=1}
gsm admin email enabled show
gsm admin email set "{email_addr}"
gsm admin email show
gsm dtmf sms pin enabled set {OFF=0|ON=1}
gsm dtmf sms pin enabled show
gsm dtmf sms master pin set "{pin_num}"
97
Expert Net Control 2111/2191
enables different event types
shows what event types are enabled
sets for what phonebook entries SMS are sent
shows for what phonebook entries SMS are sent
sets maximum value for sensor
shows maximum value for sensor
sets minimum value for sensor
shows minimum value for sensor
sets hysterese value for sensor
shows hysterese value for sensor
sets publish mode
shows publish mode
sets mqtt retain
shows if mqtt retain set
sets publish time interval
shows publish time interval
sets publish delta value
shows publish delta value
sets Port for Power Port Switching actions
shows Port for Power Port Switching actions
sets Port state for Power Port Switching actions
shows Port state for Power Port Switching actions
sets sensor Min/Max measurement period
shows sensor Min/Max measurement period
enters cmd group "gsm"
activates the built-in GSM module
shows if the built-in GSM module is enabled
sets PIN and switches the PIN request on
shows the PIN of the SIM card
sets the phone number of the SIM card
shows the phone number of the SIM card
sets phone number for SMS status changes
shows phone number for SMS status changes
enables status changes sent via SMS
shows if status changes via SMS are enabled
enables status changes sent via email
shows if status changes via email are enabled
sets status email recipient address
shows status email recipient address
enables necessary pin for port changes
shows if pin is needed for port changes
sets master pin for port changes
6
6
6
6
6
6
6
6
6
6
6
6
6
6
