Spezifikationen
input {port_num} {LOW=0|HIGH=1} port set
{port_num}
input {port_num} {LOW=0|HIGH=1} port show
input {port_num} {LOW=0|HIGH=1} state set
{OFF=0|ON=1|DISABLED=2}
input {port_num} {LOW=0|HIGH=1} state show
input volt3 state show
input volt12 state set {OFF=0|VLO=1|VHI=2}
input volt12 state show
ip4
ip4 hostname set "{name}"
ip4 hostname show
ip4 address set "{ip_address}"
ip4 address show
ip4 netmask set "{ip_address}"
ip4 netmask show
ip4 gateway set "{ip_address}"
ip4 gateway show
ip4 dns set "{ip_address}"
ip4 dns show
ip4 dhcp enabled set {OFF=0|ON=1}
ip4 dhcp enabled show
ip6
ip6 enabled set {OFF=0|ON=1}
ip6 enabled show
ip6 routadv enabled set {OFF=0|ON=1}
ip6 routadv enabled show
ip6 dhcp enabled set {OFF=0|ON=1}
ip6 dhcp enabled show
ip6 address show
ip6 gateway show
ip6 dns show
ip6 manual enabled set {OFF=0|ON=1}
ip6 manual enabled show
ip6 manual address {1..4} set "{ip_address}"
ip6 manual address {1..4} show
ip6 manual gateway set "{ip_address}"
ip6 manual gateway show
ip6 manual dns {1..2} set "{ip_address}"
ip6 manual dns {1..2} show
ipacl
ipacl ping enabled set {OFF=0|ON=1}
ipacl ping enabled show
ipacl enabled set {OFF=0|ON=1}
ipacl enabled show
ipacl filter {ipacl_num} set "{dns_name}"
ipacl filter {ipacl_num} show
modbus
modbus enabled set <off=0/on=1>
modbus enabled show
modbus port set <ip_port>
modbus port show
mqtt
mqtt {broker_idx} enabled set {OFF=0|ON=1}
mqtt {broker_idx} enabled show
mqtt {broker_idx} server set "{dns_name}"
mqtt {broker_idx} server show
mqtt {broker_idx} tls enabled set {OFF=0|ON=1}
mqtt {broker_idx} tls enabled show
mqtt {broker_idx} port set {ip_port}
mqtt {broker_idx} port show
mqtt {broker_idx} user set "{username}"
mqtt {broker_idx} user show
mqtt {broker_idx} passwd set "{passwd}"
mqtt {broker_idx} passwd hash set "{passwd}"
mqtt {broker_idx} client set "{name}"
mqtt {broker_idx} client show
mqtt {broker_idx} qos set {QOS0=0|QOS1=1}
mqtt {broker_idx} qos show
mqtt {broker_idx} keepalive set {num_secs}
mqtt {broker_idx} keepalive show
91
Expert Net Control 2111/2191
sets Port for Power Port Switching actions
shows Port for Power Port Switching actions
sets Port state for Power Port Switching actions
shows Port state for Power Port Switching actions
shows state of 3V input voltage {ON=1|VERR=3}
sets state of 12V input voltage
shows state of 12V input voltage {OFF=0|VLO=1|
VHI=2|VERR=3} incl possible error condition
enters cmd group "ip4"
sets device hostname
shows device hostname
sets IPv4 address
shows IPv4 address
sets IPv4 netmask
shows IPv4 netmask
sets IPv4 gateway address
shows IPv4 gateway address
sets IPv4 DNS server address
shows IPv4 DNS server address
enables IPv4 DHCP on/off
shows IPv4 DHCP state
enters cmd group "ip6"
enables IPv6 on/off
shows if IPv6 is enabled
enables IPv6 router advertisement
shows IPv6 router advertisement state
enables IPv6 DHCP on/off
shows if IPv6 DHCP is enabled
show all IPv6 addresses
show all IPv6 gateways
show all IPv6 DNS server
enables manual IPv6 addresses
shows if manual IPv6 addresses are enabled
sets manual IPv6 address
shows manual IPv6 address
sets manual IPv6 gateway address
shows manual IPv6 gateway address
sets manual IPv6 DNS server address
shows manual IPv6 DNS server address
enters cmd group "ipacl"
enables ICMP ping on/off
shows if ICMP ping enabled
enable IP filter on/off
shows if IP filter enabled
sets IP filter {ipacl_num}
shows IP filter {ipacl_num}
enters cmd group "modbus"
enables Modbus TCP support
shows if Modbus is enabled
sets Modbus TCP port
shows Modbus TCP port
enters cmd group "mqtt"
enable mqtt
shows if mqtt enabled
sets broker name
shows broker name
enable TLS
shows if TLS enabled
set broker TCP/IP port
shows broker TCP/IP port
sets username
shows username
sets password
sets hashed passwd
sets client name
shows client name
sets QoS level
shows QoS level
sets keep-alive time
shows keep-alive time
3
3
3
3
3
3
3
3
3
4
4
4
3
3
3
3
