3. PANEL FUNCTION INSTRUCTION:

Picture 3-1 ARC 200
Function description
5
1 VRD Change-over switch
2 VRD Indicator light
3 Digital ammeter
4 protection lamp
Welding current
5
adjustment
6 Positive output terminal
7 Negative output terminal
8 Earth connecting screw
9 Power switch
10 Input power line
