1.1 INVERTER MMA/ARC WELDER SERIES FEATURES：
ARC 160 IGBT series inverter welding machine is my company's R & D design of manual arc inverter
welding machine, has the following advantages:
①
Strong ability against the power fluctuation, it can work normally under the fluctuation of ±15%;
②
Fashionable appearance, small size, light weight and easy to move;
③
Using the three-proofed structure against the dust, moisture and corrosion, very considerable protection
for all the electronic components
④
This series of manual arc welding machine using current-mode PWM pulse width adjustment technology
IGBT inverter technology, high-power fast recovery diode application technology, product reliability,
stability, higher.
⑤
With under voltage, overheating, overcurrent, lack of protection, to ensure product reliability.
⑥
Stable output performance, real-time monitoring of the welding output power, the effective management
of the output current to ensure welding welding reliability.
⑦
Has a good dynamic characteristics, easy arc, arc stability, easy to control the pool.
⑧
With precise preset welding current to make sure good welding result and energy saving, more easy to
operate and suitable for different thickness work-piece, thin plate in small current and thick plate in large
current.
1.2 APPLICATION:
Suitable for welding of carbon steel, alloy steel, non-ferrous metals, suitable for boiler pressure-melt
industrial power plants, aerospace manufacturing, industrial, automotive and vehicle manufacturing,
construction and other related metals welding industry.
1.3 MODEL EXPLANATION:
ARC
1.4 LABEL EXPLANATIONS:
Read all safrty regulations and
Disconnet the machine from the mains
before installation or adjustment
note: Be sure to identify the product model on the nameplate, the same product model may
have different parameters.
instructions
Wear a welding mask
Wear a dust mask
Rotation direction
3
indicate parameter difference
indicate the product name
ARC/MMA inverter welder
Attention. Warning of possible user health
Movement direction
Earthing loop
damage
Unlocked
Locked
