Turning the instrument on

Insert the DC plug of the supplied AC adapter into the
DC inlet of the EC150, and then connect the AC plug
to a wall socket; then press the POWER switch. When
the instrument is on, the LEDs on the control panel
will light up. To turn the instrument off, press the
POWER switch again.
Note: When the instrument is turned off, all parameters are reset.

Adjusting the volume

Move the MASTER VOLUME slider towards the right to increase the volume;
towards the left to decrease the volume. The maximum is "10"; the minimum
(silence) is "0". This control adjusts the output level of the headphones, the internal
speakers and of the OUTPUTs. It does not control the input level of the audio
source connected to the INPUTs.
Note: It is always better to start with a low volume and then increase gradually.

Listening to the Demo

The EC150 contains 30 pre-recorded demo songs. Listen to them to experience the
rich sound and expressive potential of this instrument.
Listen to all songs at once.
mand.
Press the DEMO button (or keep the TRANSPOSE/FUNCTION button pressed,
1
and press E1 on the keyboard). The sound selection buttons LED will blink sequen-
tially from left to right. After a few seconds, playback will begin. All demo songs
will be played back. After the last song, the playback will begin again from the first
song.
During playback, you can press a sound selection button to repeat just the current
2
bank of ten demo songs. (There are three banks of ten demo songs each: 1-10, 11-
20, 21-30).
For example, if you press the CHOIR button while song number 1 is playing, song
number 10 will immediately start playing, and the playback will cycle from song 1
through song 10.
Press the DEMO button to stop the playback and exit the demo mode.
3
Listen to a specified song.
14
You can listen to all demo songs with a single com-
You can select just one demo song to be played back.
to an AC outlet
DC IN
Chapter 2
