TOURNUS EQUIPEMENT ROLL' Service Installations-, Betriebs- Und Flegeanweisung Seite 16

Tr Electronic control thermostat.
Ts Double-pole safety thermostat.
V Centrifugal fan.
L Temperature limiter.
Re Shielded heating element.
Tr
Probe
GRAPHIC SYMBOLS OF DIAGRAMS
Plug
Fan
Front panel
control
•
Spiral power supply cord 3G1,5 H05VVF with moulded plug to be connected to a 16 A single-phase
current socket protected with a 30mA differential circuit-breaker and an omni-pole cut-out device
(switch or circuit-breaker) with a contact opening distance of less than 3mm.
NB: If the power supply cord is damaged, it must be replaced by the manufacturer, its after-sales
service or a similar qualified person to avoid danger.
WIRING DIAGRAMS
Probe
Pump
Temperature
Contactor
Lamp
limiter
CONNECTION
Model without hygrometry
V
Main - On/Off
Heating - On/Off
Heating Set value up
Heating Set value down
- 16 -
104 000 Iss.13
104 000 Iss.13
L
P
Re
