Power supply
Mains operation:
Mains voltage:
Frequency:
Adaptor voltage output:
Adaptor current output:
Battery operation:
Measuring range
Max. load capacity:
Division:
Accuracy:
Ambient conditions
Operating temperature:
Storage and Transport
temperature:
Humidity:
Air pressure:
Device classification
Mode of operation:
Degree of protection:
Battery mode:
AC adapter mode:
Software:
Wireless:
Frequency:
Transmission power:
Range:
Housing
Dimensions:
Net weight:
Material:
Protection class:
Service Lifetime:
M320600-210429-Rev004-UM-en

9. Technical Data

Use only with Mains Adapter UES06WOCP-060100SPA
100 – 240 V AC, 0.2A
50/60 Hz
6 V DC
1.0 A (max.)
4 x 1.5 V AA alkaline batteries
(> 5000 measurements / >100 h operating time)
250 kg
50 g < 50 kg > 100 g
0≤25,0kg: 25,1≤50,0kg:
±50g ±100g
+10°C to +40°C
-20°C to +60°C
10% - 95% RH
700 hPa - 1060 hPa
The combination of adapter and main unit are specified as an ME
EQUIPMENT. Adapter is considered as part of ME equipment.
Continuous operation
Type BF applied part (scale top surface)
Internally powered ME equipment
Class II ME equipment
The software version is displayed when the scale is switched on.
2402 MHz to 2483.5 MHz
+4 dbm
10 metres
400 x 350 x 65 mm
4.2 kg
ABS plastic
IP20; the device is protected against solid foreign objects with a
diameter of ≥ 12.5 mm. It is not protected against water drops.
The design provides you with a service lifetime of 8 years.
50,1kg≤200,0kg:
±200g
200,1≤250,0kg:
±300g
