Thank you for your decision to purchase this high quality body analyser scale. Please
read this instruction manual prior to the start up and keep this user instruction careful
so as to have this information on hand whenever it is needed.

1. How does the body analyser work?

Through this new revolutionary scale you will be able to get information about your
body composition with reference to your weight, body fat %, body water % and BMI
(body mass index). First of all you have to enter once your personal data like gender
(male / female), body height and age under your selected personal memory location.
Afterwards a measurement is as simple as on a normal bathroom scale. You have
only to push your personal memory location, step on the scale and within a few
seconds your measured values will be indicated. The analysis is based on the
measurement of the body's electrical resistance. A low, safe electrical signal passes
freely through fluids contained in lean tissue, such as muscle and blood, but meets
resistance passing through fat tissue. The body analyser accurately measures the
resistance and with reference to your personal data use it to calculate elements of
body composition.

2. Conditions to use

If possible the measurement should be done undressed but always barefoot.
By nature a body is subject of fluctuations (for example: loss of water after taking
exercise or after a sauna visit, after a meal, etc.). To enable comparable readings it is
important to take the measurements as possible always under the same conditions.
In order to ensure that the results of analysis are accurate and consistent, please keep
the measurement conditions constant always at the same daytime. In the morning,
directly after you've woken up, your body will be dehydrated and also the majority of
fluid will be stored in the central trunk area. This means that the resistance is relatively
high because of the poor conductivity in the body. By intensify moving during the day
progresses the fluid becomes more evenly distributed through the limbs and
increasing the accuracy of the readings. To get a realistic result it is important to take
your readings at the same time and under the same conditions every day. The easiest
way to stick the rule, measure always in the morning, 15 minutes after you've got up,
either before or after you've gone to the bathroom.
In spite of a very low electrical signal, this body analyzer is not suitable for
persons with heart pacemaker or other electronic medical implants! There is no
risk for persons with none electronic implant for instance a titanium plate in the knee.
However, metal conducts the electric current extremely well and therefore the scale
implicates the body fat value "beautified" – means the actual body fat value is higher
as indicated. However, tendencies may be determined as well.
All manuals and user guides at all-guides.com
2

8. Error Messages

"LO" = Batteries are used up - Please replace the batteries with the intended
type (4 x AAA).
"O_Ld" = Overload - The weight exceeds the maximum capacity of 180 kg.
Please immediately remove the critical load to avoid load cell
damage.
"Err" = Incorrect weighing / measuring process - For example, the scale is
placed unstable, you do not remain stationary on the weighing
platform or if body fat is less than 3% or higher than 55%.

9. Technical Data

Capacity x graduation: max. 180 kg x 100 g
Display resolution: body fat: 0.1%
Display resolution: body water: 0.1%
Display resolution: muscle mass: 0.1%
Personal memory loc.: 12 positions
Age: 10 – 99 years
Body height: 100 – 220 cm
Dimensions: 325 mm x 310 mm x 34 mm
Batteries: 3 x AAA (included)
Subject to technical modifications
10. Warranty
ADE warrants for a period of 3 years from the date of purchase that it will remedy any
defects due to faulty material or workmanship free of charge by repair or replacement.
When purchasing, please have the warranty coupon signed and stamped by the dealer.
When making a guarantee claim, please return the weighing scale together with the
guarantee card including the reason of complaint to your dealer.
CE-Conformity. This device features radio interference
suppression in compliance with valid EC Regulation 2004/108
Note: The displayed value may be adversely affected under extreme electromagnetic
influences, e.g. when using a radio unit in the immediate vicinity of the device. Once the
interference has been rectified, the product can once again be used for its intended
purpose. The device may have to be switched on again.
