AVENTICS specific
448 Low flow cut-off Float
(0x1C0) input
449 Input smoothing UInt
(0x1C1) filter for flow
450 Flow measuring UInt
(0x1C2) mode
453 Input zero point Float
(0x1C5) offset for pres-
sure
454 Input smoothing UInt
(0x1C6) filter for pressure
458 Input smoothing UInt
(0x1CA) filter for temper-
ature
481 Signal quality 1 UInt
(0x1E1) (sensor robust-
ness)
482 Signal quality 2 UInt
(0x1E2)
483 Signal quality 3 UInt
(0x1E3)
484 Signal quality 4 UInt
(0x1E4)
485 PowerUp UInt
(0x1E5) counter
486 Power supply Float
(0x1E6) sensor
487 Sensor Float
(0x1E7) temperature
488 Mass flow Record
(0x1E8) statistics
1 (0x01) Minimum Bit (64)
2 (0x02) Maximum Bit (32)
3 (0x03) Average value Bit (0)
489 Flow speed Record
(0x1E9) statistics
490 Volume flow Record
(0x1EA) statistics
491 Temperature Record
(0x1EB) statistics
492 Pressure Record
(0x1EC) statistics
493 Statistics dura- UInt
(0x1ED) tion since reset
496 Counter status UInt
(0x1F0) since reset
502 Active messages Record
(0x1F6)
1 (0x01) Message 1 Bit
number (1104)
AVENTICS™ IO-Link AF2 | R412027828-BAL-001-AA | English
4 rw 0.0 ... 10.0
bytes
8 bits rw 0 = off
1 = 100ms
2 = 200ms
5 = 500ms
10 = 1sec
20 = 2sec
50 = 5sec
100 = 10sec
8 bits rw 0 = standard
4 rw -0.5 ... 0.5 [bar]
bytes
8 bits rw 0 = off
1 = 100ms
2 = 200ms
5 = 500ms
10 = 1sec
20 = 2sec
50 = 5sec
100 = 10sec
8 bits rw 0 = off
1 = 100ms
2 = 200ms
5 = 500ms
10 = 1sec
20 = 2sec
50 = 5sec
100 = 10sec
8 bits ro 0 ... 100 [%]
8 bits ro 0 ... 100 [%]
8 bits ro 0 ... 100 [%]
8 bits ro 0 ... 100 [%]
32 bits ro
4 ro [V]
bytes
4 ro (Parameter in 0.1°C) [°C]
bytes
12 ro
bytes
4 ro
bytes
4 ro
bytes
4 ro
bytes
12 ro See index 488
bytes
12 ro See index 488
bytes
12 ro See index 488
bytes
12 ro See index 488
bytes
32 bits ro See index 488
32 bits ro Reset process data rVolume, rMass,
rEnergy
140 ro 4 active messages with highest prior-
bytes ity
16 bits ro
AVENTICS specific
2 (0x02) Message 1 level Bit
(1096)
3 (0x03) Message 1 Bit (840) 32
description
4 (0x04) Message 2 Bit (824) 16 bits ro
number
5 (0x05) Message 2 level Bit (816) 8 bits
6 (0x06) Message 2 Bit (560) 32
description
7 (0x07) Message 3 Bit (544) 16 bits ro
number
8 (0x08) Message 3 level Bit (536) 8 bits
9 (0x09) Message 3 Bit (280) 32
description
10 (0x0A) Message 4 Bit (264) 16 bits ro
number
11 (0x0B) Message 4 level Bit (256) 8 bits
12 (0x0C) Message 4 Bit (0)
description
17342 Hardware identi- String
(0x43BE) fication key
ro = read only, rw = read/write
Standard command
2 (0x02) Standard wo
command
wo = write only
8 bits ro 0 = no message
1 = information
2 = warning
3 = error
ro
bytes
ro 0 = no message
1 = information
2 = warning
3 = error
ro
bytes
ro 0 = no message
1 = information
2 = warning
3 = error
ro
bytes
ro 0 = no message
1 = information
2 = warning
3 = error
32 ro
bytes
32 ro
bytes
83 BM_ACTIVATE
128 Reset device
130 Restore state on delivery
210 Reset all statistics values
211 Reset all counter values
