When installing please comply with the wiring diagram. All leads to
be connected must be dead. The table below shows the terminal
assignments:
Termi-
nal
1.1/1.5 Input signal 1 (I1)
2.1/2.5 Input signal 2 (I2)
3.1/3.5 Input signal 3 (I3)
4.1/4.5 Input signal 4 (I4)
1.3

Operating voltage

1.4
Connections between the Dupline signal and the 24 V supply, or
connections to earth potential, will cause malfunctions and are not
permissible. Check that the polarity of the supply voltage and the
Dupline signal is correct.
When connecting the components, ensure that the maximum torque at
the clamps does not exceed 0.6 Nm.

4. Commissioning and configuring

To ensure successful commissioning, please perform the following
steps in the order in which they are listed below:
5. Familiarise yourself with how to operate the unit:
6. Configure the system settings:
7. Configure the addresses of the inputs:
8. Configure the switching thresholds of the inputs:
Please also note the overview of the menu structure on page 27.
Description
Dupline signal
conductor (-)
0 V DC
Termi-
nal
1.2/1.6 Input signal 5 (I5)
2.2/2.6 Input signal 6 (I6)
3.2/3.6 Input signal 7 (I7)
4.2/4.6 Input signal 8 (I8)
Dupline signal
1.7
conductor (+)
Operating voltage
1.8
DE EN
Description
+24 V DC
see below
see below
see page 21
see page 21
