Operation of chair

8.1

Duty cycle (continuous operation) of electrical motors

The electrical motors are designed for a duty cycle of approximately 6 minutes at full load. Continuous
operations exceeding that time period may cause overheat conditions and permanent damage to the
transformer.
8.1.1

Battery charge status (see also 7.2)

After discharging the battery down to approximately 20% of total capacity, the chair will move signifi-
cantly slower, indicating that the battery is due for recharging. A total discharge may cause damage to
the battery.
8.2

Entry and exit position

The minimum seat cushion height
is at approximately 68 cm. A fold
away footrest may be used to as-
sist smaller or physically incapac-
itated patients to enter into or
get out of the chair.
Fold away footrest
8.2.1

Foot rest adapter (277.950300)

In order to assist smaller patients with shorter legs to comfortably sit in the chair, foot rest adapters
are available either as a single or a stackable dual block.
NOTE
These adapters are NOT designed as a STEP IN aid. If needed, attach the adapters after the patient has
been seated in the chair.
277g001d-e_ak5010_3rd ed_MDR_ REV 7.0.docx26.05.2021
Attach single block:
Tilt and slide tongue into the
notch
Attach dual block:
First, slide the 2 blocks on
top of each other and then
proceed like above.
